Smart Grid Management on Alpine Linux ⚡

Smart grid management is like having an intelligent brain for your electrical network! 🧠 It monitors energy flow, balances supply and demand, and integrates renewable sources seamlessly. Let’s build a complete smart grid management system on Alpine Linux! 🚀

What is a Smart Grid? 🤔

A smart grid includes:

• Real-time monitoring - Track energy usage instantly
• Demand response - Adjust consumption automatically
• Renewable integration - Solar, wind, and battery systems
• Grid analytics - Predict and optimize energy flow
• Two-way communication - Devices talk to the grid

Think of it as upgrading your power grid to the digital age! ⚡

Installing Core Components 📦

Set up the smart grid infrastructure:

# Update package list
sudo apk update

# Install MQTT broker for device communication
sudo apk add mosquitto mosquitto-clients

# Install time-series database
sudo apk add influxdb telegraf

# Install Python for analytics
sudo apk add python3 py3-pip python3-dev
sudo apk add gcc musl-dev linux-headers

# Install Node.js for real-time dashboard
sudo apk add nodejs npm

# Install monitoring tools
sudo apk add prometheus grafana

Setting Up Energy Monitoring 📊

Create the monitoring infrastructure:

# Create project structure
mkdir -p ~/smart-grid/{devices,analytics,dashboard,config}
cd ~/smart-grid

# Smart meter simulator
cat > devices/smart_meter.py << 'EOF'
#!/usr/bin/env python3
import paho.mqtt.client as mqtt
import json
import time
import random
import math
from datetime import datetime

class SmartMeter:
    def __init__(self, meter_id, location):
        self.meter_id = meter_id
        self.location = location
        self.mqtt_client = mqtt.Client(f"meter_{meter_id}")
        self.base_consumption = random.uniform(1.0, 3.0)  # kW base load

    def connect(self, broker="localhost", port=1883):
        """Connect to MQTT broker"""
        self.mqtt_client.connect(broker, port, 60)
        self.mqtt_client.loop_start()
        print(f"Smart meter {self.meter_id} connected to broker")

    def simulate_consumption(self):
        """Simulate realistic power consumption"""
        hour = datetime.now().hour

        # Daily consumption pattern
        if 6 <= hour <= 9:  # Morning peak
            multiplier = 1.5
        elif 17 <= hour <= 21:  # Evening peak
            multiplier = 2.0
        elif 23 <= hour or hour <= 5:  # Night low
            multiplier = 0.5
        else:  # Day normal
            multiplier = 1.0

        # Add some randomness
        consumption = self.base_consumption * multiplier
        consumption += random.uniform(-0.2, 0.2)

        # Simulate appliance usage spikes
        if random.random() < 0.1:  # 10% chance of spike
            consumption += random.uniform(1.0, 3.0)

        return max(0, consumption)

    def read_meter(self):
        """Read current meter values"""
        consumption = self.simulate_consumption()
        voltage = 230 + random.uniform(-5, 5)  # Voltage fluctuation
        current = consumption * 1000 / voltage  # Calculate current
        power_factor = 0.9 + random.uniform(-0.05, 0.05)
        frequency = 50 + random.uniform(-0.1, 0.1)  # Grid frequency

        data = {
            "meter_id": self.meter_id,
            "timestamp": datetime.now().isoformat(),
            "location": self.location,
            "consumption_kw": round(consumption, 3),
            "voltage": round(voltage, 1),
            "current": round(current, 2),
            "power_factor": round(power_factor, 3),
            "frequency": round(frequency, 2),
            "energy_today_kwh": round(consumption * datetime.now().hour, 2)
        }

        return data

    def publish_reading(self):
        """Publish meter reading to MQTT"""
        data = self.read_meter()
        topic = f"smartgrid/meters/{self.meter_id}/reading"
        self.mqtt_client.publish(topic, json.dumps(data))
        return data

    def run(self, interval=5):
        """Run continuous monitoring"""
        try:
            while True:
                reading = self.publish_reading()
                print(f"Meter {self.meter_id}: {reading['consumption_kw']} kW")
                time.sleep(interval)
        except KeyboardInterrupt:
            print(f"Meter {self.meter_id} shutting down")
            self.mqtt_client.loop_stop()
            self.mqtt_client.disconnect()

if __name__ == "__main__":
    # Create multiple smart meters
    meters = [
        SmartMeter("SM001", "Building A"),
        SmartMeter("SM002", "Building B"),
        SmartMeter("SM003", "Building C")
    ]

    # Connect all meters
    for meter in meters:
        meter.connect()

    # Run first meter (in production, run each in separate process)
    meters[0].run()
EOF

chmod +x devices/smart_meter.py

Solar Panel Integration ☀️

Monitor renewable energy sources:

# Solar panel monitor
cat > devices/solar_monitor.py << 'EOF'
#!/usr/bin/env python3
import paho.mqtt.client as mqtt
import json
import time
import math
from datetime import datetime

class SolarPanel:
    def __init__(self, panel_id, capacity_kw, location):
        self.panel_id = panel_id
        self.capacity_kw = capacity_kw
        self.location = location
        self.mqtt_client = mqtt.Client(f"solar_{panel_id}")
        self.efficiency = 0.85  # 85% efficiency

    def connect(self, broker="localhost"):
        self.mqtt_client.connect(broker, 1883, 60)
        self.mqtt_client.loop_start()

    def calculate_solar_output(self):
        """Calculate solar panel output based on time of day"""
        now = datetime.now()
        hour = now.hour + now.minute / 60

        # Sunrise at 6 AM, sunset at 6 PM (simplified)
        if 6 <= hour <= 18:
            # Solar intensity curve (bell curve)
            peak_hour = 12
            intensity = math.exp(-((hour - peak_hour) ** 2) / 18)

            # Weather factor (random clouds)
            weather_factor = 0.7 + random.uniform(0, 0.3)

            # Calculate output
            output = self.capacity_kw * intensity * weather_factor * self.efficiency
        else:
            output = 0  # No sun at night

        return max(0, output)

    def get_panel_data(self):
        """Get current panel data"""
        output_kw = self.calculate_solar_output()
        temperature = 25 + (output_kw / self.capacity_kw) * 20  # Panel temp

        data = {
            "panel_id": self.panel_id,
            "timestamp": datetime.now().isoformat(),
            "location": self.location,
            "output_kw": round(output_kw, 3),
            "capacity_kw": self.capacity_kw,
            "efficiency": round(output_kw / self.capacity_kw * 100, 1),
            "temperature_c": round(temperature, 1),
            "voltage_dc": round(400 + output_kw * 10, 1),
            "current_dc": round(output_kw * 1000 / 400, 2)
        }

        return data

    def publish_data(self):
        """Publish solar panel data"""
        data = self.get_panel_data()
        topic = f"smartgrid/solar/{self.panel_id}/status"
        self.mqtt_client.publish(topic, json.dumps(data))
        return data

    def run(self, interval=10):
        """Run continuous monitoring"""
        try:
            while True:
                data = self.publish_data()
                print(f"Solar {self.panel_id}: {data['output_kw']} kW ({data['efficiency']}%)")
                time.sleep(interval)
        except KeyboardInterrupt:
            self.mqtt_client.loop_stop()
            self.mqtt_client.disconnect()

# Battery storage system
class BatteryStorage:
    def __init__(self, battery_id, capacity_kwh, max_power_kw):
        self.battery_id = battery_id
        self.capacity_kwh = capacity_kwh
        self.max_power_kw = max_power_kw
        self.current_charge_kwh = capacity_kwh * 0.5  # Start at 50%
        self.mqtt_client = mqtt.Client(f"battery_{battery_id}")

    def connect(self, broker="localhost"):
        self.mqtt_client.connect(broker, 1883, 60)
        self.mqtt_client.loop_start()

        # Subscribe to grid commands
        self.mqtt_client.on_message = self.on_message
        self.mqtt_client.subscribe(f"smartgrid/battery/{self.battery_id}/command")

    def on_message(self, client, userdata, msg):
        """Handle charging/discharging commands"""
        try:
            command = json.loads(msg.payload.decode())
            if command["action"] == "charge":
                self.charge(command.get("power_kw", 1.0))
            elif command["action"] == "discharge":
                self.discharge(command.get("power_kw", 1.0))
        except Exception as e:
            print(f"Error processing command: {e}")

    def charge(self, power_kw):
        """Charge battery"""
        power = min(power_kw, self.max_power_kw)
        energy = power * (5/3600)  # 5 second interval in hours
        self.current_charge_kwh = min(
            self.current_charge_kwh + energy,
            self.capacity_kwh
        )

    def discharge(self, power_kw):
        """Discharge battery"""
        power = min(power_kw, self.max_power_kw)
        energy = power * (5/3600)
        self.current_charge_kwh = max(
            self.current_charge_kwh - energy,
            0
        )

    def get_status(self):
        """Get battery status"""
        soc = (self.current_charge_kwh / self.capacity_kwh) * 100

        return {
            "battery_id": self.battery_id,
            "timestamp": datetime.now().isoformat(),
            "state_of_charge": round(soc, 1),
            "current_charge_kwh": round(self.current_charge_kwh, 2),
            "capacity_kwh": self.capacity_kwh,
            "max_power_kw": self.max_power_kw,
            "available_power_kw": self.max_power_kw if soc > 10 else 0,
            "status": "charging" if soc < 90 else "ready"
        }

    def publish_status(self):
        """Publish battery status"""
        status = self.get_status()
        topic = f"smartgrid/battery/{self.battery_id}/status"
        self.mqtt_client.publish(topic, json.dumps(status))
        return status

if __name__ == "__main__":
    import random

    # Create solar panel
    solar = SolarPanel("SOLAR001", 10.0, "Rooftop A")
    solar.connect()

    # Create battery
    battery = BatteryStorage("BAT001", 50.0, 5.0)
    battery.connect()

    # Run solar panel monitoring
    solar.run()
EOF

Grid Analytics Engine 🧮

Process and analyze grid data:

# Grid analytics
cat > analytics/grid_analytics.py << 'EOF'
#!/usr/bin/env python3
import paho.mqtt.client as mqtt
import json
from influxdb_client import InfluxDBClient, Point
from datetime import datetime, timedelta
import numpy as np
from collections import defaultdict

class GridAnalytics:
    def __init__(self):
        self.mqtt_client = mqtt.Client("grid_analytics")
        self.influx_client = InfluxDBClient(
            url="http://localhost:8086",
            token="your-token",
            org="smartgrid"
        )
        self.write_api = self.influx_client.write_api()

        # Real-time data storage
        self.meter_data = defaultdict(dict)
        self.solar_data = defaultdict(dict)
        self.battery_data = defaultdict(dict)

        # Grid statistics
        self.total_consumption = 0
        self.total_generation = 0
        self.grid_frequency = 50.0

    def connect(self):
        """Connect to MQTT broker"""
        self.mqtt_client.on_connect = self.on_connect
        self.mqtt_client.on_message = self.on_message
        self.mqtt_client.connect("localhost", 1883, 60)
        self.mqtt_client.loop_start()

    def on_connect(self, client, userdata, flags, rc):
        """Subscribe to all grid topics"""
        print("Connected to MQTT broker")
        client.subscribe("smartgrid/+/+/+")

    def on_message(self, client, userdata, msg):
        """Process incoming messages"""
        try:
            topic_parts = msg.topic.split('/')
            device_type = topic_parts[1]
            device_id = topic_parts[2]
            data = json.loads(msg.payload.decode())

            # Store data by type
            if device_type == "meters":
                self.process_meter_data(device_id, data)
            elif device_type == "solar":
                self.process_solar_data(device_id, data)
            elif device_type == "battery":
                self.process_battery_data(device_id, data)

            # Run analytics
            self.analyze_grid_state()

        except Exception as e:
            print(f"Error processing message: {e}")

    def process_meter_data(self, meter_id, data):
        """Process smart meter data"""
        self.meter_data[meter_id] = data

        # Store in InfluxDB
        point = Point("meter_reading") \
            .tag("meter_id", meter_id) \
            .tag("location", data.get("location", "unknown")) \
            .field("consumption_kw", data["consumption_kw"]) \
            .field("voltage", data["voltage"]) \
            .field("current", data["current"]) \
            .field("power_factor", data["power_factor"]) \
            .field("frequency", data["frequency"]) \
            .time(datetime.utcnow())

        self.write_api.write(bucket="smartgrid", record=point)

    def process_solar_data(self, panel_id, data):
        """Process solar panel data"""
        self.solar_data[panel_id] = data

        # Store in InfluxDB
        point = Point("solar_output") \
            .tag("panel_id", panel_id) \
            .tag("location", data.get("location", "unknown")) \
            .field("output_kw", data["output_kw"]) \
            .field("efficiency", data["efficiency"]) \
            .field("temperature_c", data["temperature_c"]) \
            .time(datetime.utcnow())

        self.write_api.write(bucket="smartgrid", record=point)

    def process_battery_data(self, battery_id, data):
        """Process battery data"""
        self.battery_data[battery_id] = data

        # Store in InfluxDB
        point = Point("battery_status") \
            .tag("battery_id", battery_id) \
            .field("state_of_charge", data["state_of_charge"]) \
            .field("current_charge_kwh", data["current_charge_kwh"]) \
            .field("available_power_kw", data["available_power_kw"]) \
            .time(datetime.utcnow())

        self.write_api.write(bucket="smartgrid", record=point)

    def analyze_grid_state(self):
        """Analyze current grid state"""
        # Calculate totals
        self.total_consumption = sum(
            m["consumption_kw"] for m in self.meter_data.values()
        )
        self.total_generation = sum(
            s["output_kw"] for s in self.solar_data.values()
        )

        # Grid balance
        grid_balance = self.total_generation - self.total_consumption

        # Publish grid state
        grid_state = {
            "timestamp": datetime.now().isoformat(),
            "total_consumption_kw": round(self.total_consumption, 2),
            "total_generation_kw": round(self.total_generation, 2),
            "grid_balance_kw": round(grid_balance, 2),
            "renewable_percentage": round(
                (self.total_generation / self.total_consumption * 100)
                if self.total_consumption > 0 else 0, 1
            ),
            "num_meters": len(self.meter_data),
            "num_solar": len(self.solar_data),
            "num_batteries": len(self.battery_data)
        }

        self.mqtt_client.publish(
            "smartgrid/analytics/state",
            json.dumps(grid_state)
        )

        # Demand response signals
        if grid_balance < -5:  # High demand
            self.trigger_demand_response("reduce", abs(grid_balance))
        elif grid_balance > 5:  # Excess generation
            self.trigger_battery_charging(grid_balance)

    def trigger_demand_response(self, action, amount_kw):
        """Send demand response signals"""
        dr_signal = {
            "timestamp": datetime.now().isoformat(),
            "action": action,
            "amount_kw": amount_kw,
            "duration_minutes": 15
        }

        self.mqtt_client.publish(
            "smartgrid/demand_response/signal",
            json.dumps(dr_signal)
        )

    def trigger_battery_charging(self, excess_kw):
        """Manage battery charging with excess power"""
        available_batteries = [
            b for b in self.battery_data.values()
            if b["state_of_charge"] < 90
        ]

        if available_batteries:
            power_per_battery = excess_kw / len(available_batteries)

            for battery in available_batteries:
                command = {
                    "action": "charge",
                    "power_kw": min(power_per_battery, battery["max_power_kw"])
                }

                self.mqtt_client.publish(
                    f"smartgrid/battery/{battery['battery_id']}/command",
                    json.dumps(command)
                )

    def predict_demand(self):
        """Predict future energy demand"""
        # Query historical data
        query = '''
        from(bucket: "smartgrid")
            |> range(start: -7d)
            |> filter(fn: (r) => r._measurement == "meter_reading")
            |> filter(fn: (r) => r._field == "consumption_kw")
            |> aggregateWindow(every: 1h, fn: mean)
        '''

        # Simple prediction based on historical patterns
        # In production, use ML models

    def calculate_cost_optimization(self):
        """Calculate optimal energy usage based on pricing"""
        # Time-of-use pricing
        hour = datetime.now().hour
        if 17 <= hour <= 21:  # Peak hours
            price_per_kwh = 0.25
        elif 9 <= hour <= 17:  # Mid-peak
            price_per_kwh = 0.15
        else:  # Off-peak
            price_per_kwh = 0.10

        current_cost = self.total_consumption * price_per_kwh

        return {
            "current_price_per_kwh": price_per_kwh,
            "current_hourly_cost": round(current_cost, 2),
            "recommendation": "Shift non-critical loads to off-peak hours"
        }

if __name__ == "__main__":
    analytics = GridAnalytics()
    analytics.connect()

    print("Grid Analytics Engine running...")

    try:
        while True:
            time.sleep(60)
            # Periodic reports
            cost = analytics.calculate_cost_optimization()
            print(f"Current cost: ${cost['current_hourly_cost']}/hour")

    except KeyboardInterrupt:
        print("Shutting down analytics engine")
EOF

Real-time Dashboard 📱

Create a web dashboard for grid monitoring:

# Dashboard backend
cd dashboard
npm init -y
npm install express socket.io mqtt influx

cat > server.js << 'EOF'
const express = require('express');
const http = require('http');
const socketIo = require('socket.io');
const mqtt = require('mqtt');
const { InfluxDB } = require('@influxdata/influxdb-client');

const app = express();
const server = http.createServer(app);
const io = socketIo(server);

// MQTT client
const mqttClient = mqtt.connect('mqtt://localhost:1883');

// InfluxDB client
const influxDB = new InfluxDB({
    url: 'http://localhost:8086',
    token: 'your-token'
});
const queryApi = influxDB.getQueryApi('smartgrid');

// Serve static files
app.use(express.static('public'));

// Grid state storage
let gridState = {
    totalConsumption: 0,
    totalGeneration: 0,
    gridBalance: 0,
    renewablePercentage: 0,
    meters: {},
    solar: {},
    batteries: {}
};

// MQTT subscriptions
mqttClient.on('connect', () => {
    console.log('Connected to MQTT broker');
    mqttClient.subscribe('smartgrid/+/+/+');
    mqttClient.subscribe('smartgrid/analytics/+');
});

mqttClient.on('message', (topic, message) => {
    try {
        const data = JSON.parse(message.toString());
        const topicParts = topic.split('/');

        if (topic === 'smartgrid/analytics/state') {
            gridState = { ...gridState, ...data };
            io.emit('gridState', gridState);
        } else if (topicParts[1] === 'meters') {
            gridState.meters[topicParts[2]] = data;
            io.emit('meterUpdate', { id: topicParts[2], data });
        } else if (topicParts[1] === 'solar') {
            gridState.solar[topicParts[2]] = data;
            io.emit('solarUpdate', { id: topicParts[2], data });
        } else if (topicParts[1] === 'battery') {
            gridState.batteries[topicParts[2]] = data;
            io.emit('batteryUpdate', { id: topicParts[2], data });
        }
    } catch (error) {
        console.error('Error processing message:', error);
    }
});

// API endpoints
app.get('/api/state', (req, res) => {
    res.json(gridState);
});

app.get('/api/history/:measurement/:field', async (req, res) => {
    const { measurement, field } = req.params;
    const { start = '-1h' } = req.query;

    const query = `
        from(bucket: "smartgrid")
            |> range(start: ${start})
            |> filter(fn: (r) => r._measurement == "${measurement}")
            |> filter(fn: (r) => r._field == "${field}")
            |> aggregateWindow(every: 1m, fn: mean)
    `;

    try {
        const result = [];
        await queryApi.collectRows(query).then(rows => {
            rows.forEach(row => {
                result.push({
                    time: row._time,
                    value: row._value,
                    tag: row.meter_id || row.panel_id || row.battery_id
                });
            });
        });
        res.json(result);
    } catch (error) {
        res.status(500).json({ error: error.message });
    }
});

// Socket.io connection
io.on('connection', (socket) => {
    console.log('Client connected');

    // Send current state
    socket.emit('gridState', gridState);

    // Handle control commands
    socket.on('controlCommand', (command) => {
        mqttClient.publish(
            `smartgrid/${command.device}/${command.id}/command`,
            JSON.stringify(command.payload)
        );
    });

    socket.on('disconnect', () => {
        console.log('Client disconnected');
    });
});

server.listen(3000, () => {
    console.log('Smart Grid Dashboard running on port 3000');
});
EOF

# Dashboard frontend
mkdir -p public
cat > public/index.html << 'EOF'
<!DOCTYPE html>
<html lang="en">
<head>
    <meta charset="UTF-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <title>Smart Grid Dashboard</title>
    <script src="/socket.io/socket.io.js"></script>
    <script src="https://cdn.jsdelivr.net/npm/chart.js"></script>
    <style>
        * { margin: 0; padding: 0; box-sizing: border-box; }
        body {
            font-family: -apple-system, BlinkMacSystemFont, 'Segoe UI', sans-serif;
            background: #0a0a0a;
            color: #fff;
        }
        .header {
            background: #1a1a1a;
            padding: 1rem 2rem;
            display: flex;
            justify-content: space-between;
            align-items: center;
            border-bottom: 1px solid #333;
        }
        .container {
            padding: 2rem;
            max-width: 1400px;
            margin: 0 auto;
        }
        .grid-stats {
            display: grid;
            grid-template-columns: repeat(auto-fit, minmax(250px, 1fr));
            gap: 1.5rem;
            margin-bottom: 2rem;
        }
        .stat-card {
            background: #1a1a1a;
            border-radius: 12px;
            padding: 1.5rem;
            border: 1px solid #333;
            transition: transform 0.2s;
        }
        .stat-card:hover {
            transform: translateY(-2px);
            border-color: #4CAF50;
        }
        .stat-value {
            font-size: 2.5rem;
            font-weight: bold;
            margin: 0.5rem 0;
        }
        .stat-label {
            color: #888;
            text-transform: uppercase;
            font-size: 0.85rem;
            letter-spacing: 1px;
        }
        .positive { color: #4CAF50; }
        .negative { color: #f44336; }
        .charts {
            display: grid;
            grid-template-columns: repeat(auto-fit, minmax(500px, 1fr));
            gap: 2rem;
            margin-bottom: 2rem;
        }
        .chart-container {
            background: #1a1a1a;
            border-radius: 12px;
            padding: 1.5rem;
            border: 1px solid #333;
        }
        .devices {
            display: grid;
            grid-template-columns: repeat(auto-fit, minmax(350px, 1fr));
            gap: 1.5rem;
        }
        .device-group {
            background: #1a1a1a;
            border-radius: 12px;
            padding: 1.5rem;
            border: 1px solid #333;
        }
        .device-item {
            background: #0a0a0a;
            padding: 1rem;
            margin: 0.5rem 0;
            border-radius: 8px;
            display: flex;
            justify-content: space-between;
            align-items: center;
        }
        .device-status {
            display: inline-block;
            width: 10px;
            height: 10px;
            border-radius: 50%;
            margin-right: 0.5rem;
        }
        .status-online { background: #4CAF50; }
        .status-offline { background: #f44336; }
        .solar-icon { color: #FFC107; }
        .battery-icon { color: #2196F3; }
        .meter-icon { color: #9C27B0; }
        button {
            background: #4CAF50;
            color: white;
            border: none;
            padding: 0.5rem 1rem;
            border-radius: 6px;
            cursor: pointer;
            font-size: 0.9rem;
        }
        button:hover {
            background: #45a049;
        }
        .alert {
            background: #f44336;
            padding: 1rem;
            border-radius: 8px;
            margin: 1rem 0;
            display: flex;
            align-items: center;
        }
        .alert-icon {
            font-size: 1.5rem;
            margin-right: 1rem;
        }
    </style>
</head>
<body>
    <header class="header">
        <h1>⚡ Smart Grid Control Center</h1>
        <div>
            <span id="time"></span>
            <span style="margin-left: 2rem;">Status: <span id="connection-status">Connecting...</span></span>
        </div>
    </header>

    <div class="container">
        <!-- Grid Statistics -->
        <div class="grid-stats">
            <div class="stat-card">
                <div class="stat-label">Total Consumption</div>
                <div class="stat-value" id="total-consumption">0.0</div>
                <div>kW</div>
            </div>
            <div class="stat-card">
                <div class="stat-label">Solar Generation</div>
                <div class="stat-value positive" id="total-generation">0.0</div>
                <div>kW</div>
            </div>
            <div class="stat-card">
                <div class="stat-label">Grid Balance</div>
                <div class="stat-value" id="grid-balance">0.0</div>
                <div>kW</div>
            </div>
            <div class="stat-card">
                <div class="stat-label">Renewable %</div>
                <div class="stat-value positive" id="renewable-percentage">0</div>
                <div>Percent</div>
            </div>
        </div>

        <!-- Alerts -->
        <div id="alerts"></div>

        <!-- Charts -->
        <div class="charts">
            <div class="chart-container">
                <h3>Power Flow</h3>
                <canvas id="power-chart"></canvas>
            </div>
            <div class="chart-container">
                <h3>Energy Sources</h3>
                <canvas id="sources-chart"></canvas>
            </div>
        </div>

        <!-- Devices -->
        <div class="devices">
            <!-- Smart Meters -->
            <div class="device-group">
                <h3><span class="meter-icon">📊</span> Smart Meters</h3>
                <div id="meters-list"></div>
            </div>

            <!-- Solar Panels -->
            <div class="device-group">
                <h3><span class="solar-icon">☀️</span> Solar Panels</h3>
                <div id="solar-list"></div>
            </div>

            <!-- Batteries -->
            <div class="device-group">
                <h3><span class="battery-icon">🔋</span> Battery Storage</h3>
                <div id="batteries-list"></div>
            </div>
        </div>
    </div>

    <script>
        const socket = io();
        let powerChart, sourcesChart;
        let gridState = {};

        // Initialize charts
        function initCharts() {
            // Power flow chart
            const powerCtx = document.getElementById('power-chart').getContext('2d');
            powerChart = new Chart(powerCtx, {
                type: 'line',
                data: {
                    labels: [],
                    datasets: [{
                        label: 'Consumption',
                        data: [],
                        borderColor: '#f44336',
                        tension: 0.1
                    }, {
                        label: 'Generation',
                        data: [],
                        borderColor: '#4CAF50',
                        tension: 0.1
                    }]
                },
                options: {
                    responsive: true,
                    maintainAspectRatio: false,
                    scales: {
                        y: { beginAtZero: true }
                    }
                }
            });

            // Energy sources chart
            const sourcesCtx = document.getElementById('sources-chart').getContext('2d');
            sourcesChart = new Chart(sourcesCtx, {
                type: 'doughnut',
                data: {
                    labels: ['Solar', 'Grid', 'Battery'],
                    datasets: [{
                        data: [0, 0, 0],
                        backgroundColor: ['#FFC107', '#9E9E9E', '#2196F3']
                    }]
                },
                options: {
                    responsive: true,
                    maintainAspectRatio: false
                }
            });
        }

        // Update display
        function updateDisplay(state) {
            document.getElementById('total-consumption').textContent =
                state.total_consumption_kw?.toFixed(1) || '0.0';
            document.getElementById('total-generation').textContent =
                state.total_generation_kw?.toFixed(1) || '0.0';

            const balance = state.grid_balance_kw || 0;
            const balanceEl = document.getElementById('grid-balance');
            balanceEl.textContent = balance.toFixed(1);
            balanceEl.className = balance >= 0 ? 'stat-value positive' : 'stat-value negative';

            document.getElementById('renewable-percentage').textContent =
                Math.round(state.renewable_percentage || 0);

            // Update charts
            updateCharts(state);

            // Update device lists
            updateDeviceLists(state);

            // Check for alerts
            checkAlerts(state);
        }

        function updateCharts(state) {
            // Add data point to power chart
            const time = new Date().toLocaleTimeString();

            if (powerChart.data.labels.length > 20) {
                powerChart.data.labels.shift();
                powerChart.data.datasets[0].data.shift();
                powerChart.data.datasets[1].data.shift();
            }

            powerChart.data.labels.push(time);
            powerChart.data.datasets[0].data.push(state.total_consumption_kw || 0);
            powerChart.data.datasets[1].data.push(state.total_generation_kw || 0);
            powerChart.update();

            // Update sources chart
            const solarPower = state.total_generation_kw || 0;
            const gridPower = Math.max(0, (state.total_consumption_kw || 0) - solarPower);
            const batteryPower = 0; // Calculate from battery data

            sourcesChart.data.datasets[0].data = [solarPower, gridPower, batteryPower];
            sourcesChart.update();
        }

        function updateDeviceLists(state) {
            // Update meters
            const metersList = document.getElementById('meters-list');
            metersList.innerHTML = '';

            Object.entries(state.meters || {}).forEach(([id, meter]) => {
                const item = document.createElement('div');
                item.className = 'device-item';
                item.innerHTML = `
                    <div>
                        <span class="device-status status-online"></span>
                        ${id} - ${meter.location || 'Unknown'}
                    </div>
                    <div>${meter.consumption_kw?.toFixed(2) || 0} kW</div>
                `;
                metersList.appendChild(item);
            });

            // Update solar panels
            const solarList = document.getElementById('solar-list');
            solarList.innerHTML = '';

            Object.entries(state.solar || {}).forEach(([id, solar]) => {
                const item = document.createElement('div');
                item.className = 'device-item';
                item.innerHTML = `
                    <div>
                        <span class="device-status status-online"></span>
                        ${id} - ${solar.location || 'Unknown'}
                    </div>
                    <div>${solar.output_kw?.toFixed(2) || 0} kW (${solar.efficiency || 0}%)</div>
                `;
                solarList.appendChild(item);
            });

            // Update batteries
            const batteriesList = document.getElementById('batteries-list');
            batteriesList.innerHTML = '';

            Object.entries(state.batteries || {}).forEach(([id, battery]) => {
                const item = document.createElement('div');
                item.className = 'device-item';
                item.innerHTML = `
                    <div>
                        <span class="device-status status-online"></span>
                        ${id}
                    </div>
                    <div>
                        ${battery.state_of_charge?.toFixed(1) || 0}%
                        <button onclick="chargeBattery('${id}')">Charge</button>
                    </div>
                `;
                batteriesList.appendChild(item);
            });
        }

        function checkAlerts(state) {
            const alertsDiv = document.getElementById('alerts');
            alertsDiv.innerHTML = '';

            // Check for high demand
            if (state.grid_balance_kw < -10) {
                const alert = document.createElement('div');
                alert.className = 'alert';
                alert.innerHTML = `
                    <span class="alert-icon">⚠️</span>
                    <div>
                        <strong>High Demand Alert</strong><br>
                        Grid demand exceeds generation by ${Math.abs(state.grid_balance_kw).toFixed(1)} kW
                    </div>
                `;
                alertsDiv.appendChild(alert);
            }
        }

        function chargeBattery(batteryId) {
            socket.emit('controlCommand', {
                device: 'battery',
                id: batteryId,
                payload: { action: 'charge', power_kw: 2.0 }
            });
        }

        // Socket events
        socket.on('connect', () => {
            document.getElementById('connection-status').textContent = 'Connected';
        });

        socket.on('disconnect', () => {
            document.getElementById('connection-status').textContent = 'Disconnected';
        });

        socket.on('gridState', (state) => {
            gridState = state;
            updateDisplay(state);
        });

        socket.on('meterUpdate', (data) => {
            if (!gridState.meters) gridState.meters = {};
            gridState.meters[data.id] = data.data;
            updateDisplay(gridState);
        });

        socket.on('solarUpdate', (data) => {
            if (!gridState.solar) gridState.solar = {};
            gridState.solar[data.id] = data.data;
            updateDisplay(gridState);
        });

        socket.on('batteryUpdate', (data) => {
            if (!gridState.batteries) gridState.batteries = {};
            gridState.batteries[data.id] = data.data;
            updateDisplay(gridState);
        });

        // Update time
        setInterval(() => {
            document.getElementById('time').textContent = new Date().toLocaleString();
        }, 1000);

        // Initialize
        initCharts();
    </script>
</body>
</html>
EOF

Grid Automation Rules 🤖

Implement smart grid automation:

# Automation rules engine
cat > analytics/automation_rules.py << 'EOF'
#!/usr/bin/env python3
import json
from datetime import datetime, time

class GridAutomation:
    def __init__(self, mqtt_client):
        self.mqtt_client = mqtt_client
        self.rules = self.load_rules()

    def load_rules(self):
        """Load automation rules"""
        return [
            {
                "name": "Peak Shaving",
                "condition": lambda state: state["total_consumption_kw"] > 50,
                "action": self.peak_shaving
            },
            {
                "name": "Solar Excess Storage",
                "condition": lambda state: state["grid_balance_kw"] > 5,
                "action": self.store_excess_solar
            },
            {
                "name": "Night Load Balancing",
                "condition": lambda state: self.is_night_time() and state["total_consumption_kw"] > 30,
                "action": self.night_load_balance
            },
            {
                "name": "Emergency Response",
                "condition": lambda state: state.get("grid_frequency", 50) < 49.5,
                "action": self.emergency_response
            }
        ]

    def is_night_time(self):
        """Check if it's night time"""
        current_time = datetime.now().time()
        return current_time < time(6, 0) or current_time > time(22, 0)

    def evaluate_rules(self, grid_state):
        """Evaluate all automation rules"""
        for rule in self.rules:
            if rule["condition"](grid_state):
                print(f"Triggering rule: {rule['name']}")
                rule["action"](grid_state)

    def peak_shaving(self, state):
        """Reduce peak demand"""
        # Discharge batteries
        for battery_id in state.get("batteries", {}):
            command = {
                "action": "discharge",
                "power_kw": 5.0
            }
            self.mqtt_client.publish(
                f"smartgrid/battery/{battery_id}/command",
                json.dumps(command)
            )

        # Send demand response signal
        dr_signal = {
            "action": "reduce",
            "target_reduction_kw": 10,
            "incentive_per_kwh": 0.50
        }
        self.mqtt_client.publish(
            "smartgrid/demand_response/signal",
            json.dumps(dr_signal)
        )

    def store_excess_solar(self, state):
        """Store excess solar in batteries"""
        excess_kw = state["grid_balance_kw"]

        # Charge available batteries
        available_batteries = [
            b for b in state.get("batteries", {}).values()
            if b["state_of_charge"] < 90
        ]

        if available_batteries:
            power_per_battery = excess_kw / len(available_batteries)

            for battery in available_batteries:
                command = {
                    "action": "charge",
                    "power_kw": min(power_per_battery, 5.0)
                }
                self.mqtt_client.publish(
                    f"smartgrid/battery/{battery['battery_id']}/command",
                    json.dumps(command)
                )

    def night_load_balance(self, state):
        """Balance load during night hours"""
        # Shift flexible loads to night time
        load_shift_signal = {
            "action": "shift_to_now",
            "device_types": ["water_heater", "ev_charger"],
            "duration_hours": 4
        }
        self.mqtt_client.publish(
            "smartgrid/load_control/signal",
            json.dumps(load_shift_signal)
        )

    def emergency_response(self, state):
        """Emergency grid stabilization"""
        # Shed non-critical loads
        emergency_signal = {
            "action": "emergency_shed",
            "priority_levels": [3, 4, 5],  # Shed lowest priority loads
            "reason": "Grid frequency drop"
        }
        self.mqtt_client.publish(
            "smartgrid/emergency/signal",
            json.dumps(emergency_signal)
        )

        # Discharge all available batteries
        for battery_id in state.get("batteries", {}):
            command = {
                "action": "discharge",
                "power_kw": 10.0,  # Maximum discharge
                "emergency": True
            }
            self.mqtt_client.publish(
                f"smartgrid/battery/{battery_id}/command",
                json.dumps(command)
            )
EOF

Starting the Smart Grid System 🚀

Create startup scripts:

# System startup script
cat > start_smartgrid.sh << 'EOF'
#!/bin/sh
# Start Smart Grid Management System

echo "Starting Smart Grid Management System..."

# Start MQTT broker
mosquitto -d

# Start InfluxDB
influxd &

# Start smart meters (in production, these would be real devices)
python3 devices/smart_meter.py &
python3 devices/solar_monitor.py &

# Start analytics engine
python3 analytics/grid_analytics.py &

# Start web dashboard
cd dashboard && npm start &

echo "Smart Grid System started!"
echo "Dashboard available at http://localhost:3000"

# Monitor logs
tail -f /var/log/mosquitto/mosquitto.log
EOF

chmod +x start_smartgrid.sh

Best Practices 📌

1. Redundancy - Multiple monitoring points
2. Security - Encrypt all communications
3. Scalability - Design for growth
4. Real-time processing - Minimize latency
5. Data retention - Balance storage vs. analysis needs

Troubleshooting 🔧

MQTT Connection Issues

# Test MQTT broker
mosquitto_sub -t "smartgrid/#" -v

# Check MQTT logs
sudo tail -f /var/log/mosquitto/mosquitto.log

# Test publishing
mosquitto_pub -t "smartgrid/test" -m "Hello Grid"

Data Not Appearing

# Check InfluxDB
influx
> SHOW DATABASES
> USE smartgrid
> SHOW MEASUREMENTS
> SELECT * FROM meter_reading LIMIT 10

Quick Commands 📋

# Monitor all MQTT messages
mosquitto_sub -t "smartgrid/#" -v

# Check grid state
curl http://localhost:3000/api/state | jq

# Manually control battery
mosquitto_pub -t "smartgrid/battery/BAT001/command" -m '{"action":"charge","power_kw":5}'

# View analytics
curl http://localhost:3000/api/history/meter_reading/consumption_kw?start=-1h

Conclusion 🎯

You’ve built a complete smart grid management system on Alpine Linux! From real-time monitoring to renewable integration and intelligent automation, your grid can now optimize energy distribution automatically. This system forms the foundation for a sustainable, efficient electrical infrastructure. Keep innovating with clean energy! ⚡✨
