🔒 Setting Up Nginx SSL/TLS: Simple Guide

Let me show you how to set up SSL/TLS certificates with Nginx on Alpine Linux! This will secure your website with HTTPS, protecting your visitors’ data. Think of it as adding a lock to your website’s front door!

🤔 What is SSL/TLS?

SSL/TLS creates an encrypted connection between your website and visitors. It’s like a secure tunnel that protects data as it travels. When you see the padlock icon in your browser, that’s SSL/TLS at work! It keeps passwords, credit cards, and personal info safe from hackers.

Why use SSL/TLS?

Encrypt sensitive data
Build visitor trust
Improve SEO rankings
Enable modern features
Meet security requirements

🎯 What You Need

Before starting, you’ll need:

Alpine Linux installed
Nginx web server running
Domain name (optional)
Root access
About 20 minutes

📋 Step 1: Install Required Tools

First, let’s get everything we need:

# Update packages
apk update

# Install Nginx if not already installed
apk add nginx

# Install OpenSSL for certificates
apk add openssl

# Install Certbot for Let's Encrypt
apk add certbot certbot-nginx

# Start Nginx
rc-service nginx start
rc-update add nginx

# Check Nginx is running
nginx -t
ps aux | grep nginx

📋 Step 2: Create Self-Signed Certificate

Let’s start with a self-signed certificate for testing:

# Create certificate directory
mkdir -p /etc/nginx/ssl
cd /etc/nginx/ssl

# Generate private key
openssl genrsa -out server.key 2048

# Create certificate signing request
openssl req -new -key server.key -out server.csr \
  -subj "/C=US/ST=State/L=City/O=Organization/CN=localhost"

# Generate self-signed certificate
openssl x509 -req -days 365 -in server.csr \
  -signkey server.key -out server.crt

# Create Diffie-Hellman parameters
openssl dhparam -out dhparam.pem 2048

# Set permissions
chmod 600 server.key
chmod 644 server.crt dhparam.pem

# List certificates
ls -la /etc/nginx/ssl/

📋 Step 3: Configure Nginx for SSL

Now configure Nginx to use SSL:

# Backup original config
cp /etc/nginx/nginx.conf /etc/nginx/nginx.conf.backup

# Create SSL server block
cat > /etc/nginx/conf.d/ssl-site.conf << 'EOF'
server {
    listen 443 ssl http2;
    listen [::]:443 ssl http2;
    server_name localhost;

    # SSL Certificate files
    ssl_certificate /etc/nginx/ssl/server.crt;
    ssl_certificate_key /etc/nginx/ssl/server.key;

    # SSL Configuration
    ssl_protocols TLSv1.2 TLSv1.3;
    ssl_ciphers HIGH:!aNULL:!MD5;
    ssl_prefer_server_ciphers on;
    ssl_session_cache shared:SSL:10m;
    ssl_session_timeout 10m;

    # Diffie-Hellman parameters
    ssl_dhparam /etc/nginx/ssl/dhparam.pem;

    # Security headers
    add_header Strict-Transport-Security "max-age=31536000; includeSubDomains" always;
    add_header X-Frame-Options "DENY" always;
    add_header X-Content-Type-Options "nosniff" always;
    add_header X-XSS-Protection "1; mode=block" always;

    # Document root
    root /var/www/localhost/htdocs;
    index index.html index.htm;

    location / {
        try_files $uri $uri/ =404;
    }

    # Logging
    access_log /var/log/nginx/ssl-access.log;
    error_log /var/log/nginx/ssl-error.log;
}

# Redirect HTTP to HTTPS
server {
    listen 80;
    listen [::]:80;
    server_name localhost;

    return 301 https://$server_name$request_uri;
}
EOF

# Test configuration
nginx -t

# Reload Nginx
rc-service nginx reload

📋 Step 4: Get Let’s Encrypt Certificate

For a real domain, use Let’s Encrypt:

# Stop Nginx temporarily
rc-service nginx stop

# Get certificate (replace example.com with your domain)
certbot certonly --standalone -d example.com -d www.example.com \
  --agree-tos --non-interactive --email [email protected]

# Start Nginx
rc-service nginx start

# Update Nginx config for Let's Encrypt
cat > /etc/nginx/conf.d/letsencrypt-site.conf << 'EOF'
server {
    listen 443 ssl http2;
    listen [::]:443 ssl http2;
    server_name example.com www.example.com;

    # Let's Encrypt certificates
    ssl_certificate /etc/letsencrypt/live/example.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/example.com/privkey.pem;

    # Strong SSL configuration
    ssl_protocols TLSv1.2 TLSv1.3;
    ssl_ciphers ECDHE-RSA-AES128-GCM-SHA256:ECDHE-RSA-AES256-GCM-SHA384;
    ssl_prefer_server_ciphers off;
    ssl_session_cache shared:SSL:10m;
    ssl_session_timeout 1d;
    ssl_session_tickets off;

    # OCSP stapling
    ssl_stapling on;
    ssl_stapling_verify on;
    ssl_trusted_certificate /etc/letsencrypt/live/example.com/chain.pem;

    # Security headers
    add_header Strict-Transport-Security "max-age=63072000" always;

    root /var/www/example.com;
    index index.html;

    location / {
        try_files $uri $uri/ =404;
    }
}

# HTTP to HTTPS redirect
server {
    listen 80;
    listen [::]:80;
    server_name example.com www.example.com;

    location /.well-known/acme-challenge/ {
        root /var/www/certbot;
    }

    location / {
        return 301 https://$host$request_uri;
    }
}
EOF

# Set up auto-renewal
echo "0 0,12 * * * root certbot renew --quiet --post-hook 'rc-service nginx reload'" \
  >> /etc/crontab

📋 Step 5: Test SSL Configuration

Verify everything works:

# Test with curl
curl -I https://localhost -k

# Check certificate details
openssl s_client -connect localhost:443 -servername localhost

# Test SSL protocols
openssl s_client -connect localhost:443 -tls1_2
openssl s_client -connect localhost:443 -tls1_3

# Check certificate expiration
echo | openssl s_client -connect localhost:443 2>/dev/null | \
  openssl x509 -noout -dates

# Test cipher suites
openssl s_client -connect localhost:443 -cipher 'ECDHE-RSA-AES256-GCM-SHA384'

# Check HTTP/2 support
curl -I --http2 https://localhost -k | grep HTTP

📋 Step 6: Advanced SSL Settings

Optimize your SSL configuration:

# Enable OCSP stapling for self-signed
cat >> /etc/nginx/conf.d/ssl-site.conf << 'EOF'

    # OCSP Stapling (if using CA-signed cert)
    # ssl_stapling on;
    # ssl_stapling_verify on;
    # resolver 8.8.8.8 8.8.4.4 valid=300s;
    # resolver_timeout 5s;
EOF

# Create custom error pages
mkdir -p /var/www/errors
cat > /var/www/errors/502.html << 'EOF'
<!DOCTYPE html>
<html>
<head>
    <title>502 Bad Gateway</title>
    <style>
        body { font-family: Arial; text-align: center; padding: 50px; }
        h1 { color: #e74c3c; }
    </style>
</head>
<body>
    <h1>502 Bad Gateway</h1>
    <p>The server is temporarily unable to service your request.</p>
</body>
</html>
EOF

# Add error page to config
echo "error_page 502 /errors/502.html;" >> /etc/nginx/conf.d/ssl-site.conf
echo "location /errors/ { internal; root /var/www; }" >> /etc/nginx/conf.d/ssl-site.conf

📋 Step 7: Monitor SSL Status

Create monitoring tools:

# SSL certificate checker script
cat > /usr/local/bin/check-ssl.sh << 'EOF'
#!/bin/sh
# Check SSL Certificate Status

DOMAIN="${1:-localhost}"
PORT="${2:-443}"

echo "🔒 SSL Certificate Check for $DOMAIN:$PORT"
echo "======================================"

# Get certificate info
CERT_INFO=$(echo | openssl s_client -connect $DOMAIN:$PORT -servername $DOMAIN 2>/dev/null)

if [ $? -eq 0 ]; then
    # Extract certificate
    echo "$CERT_INFO" | openssl x509 -noout -text > /tmp/cert.txt

    # Show issuer
    echo "📍 Issuer:"
    grep "Issuer:" /tmp/cert.txt | sed 's/^[ \t]*/  /'

    # Show subject
    echo "📍 Subject:"
    grep "Subject:" /tmp/cert.txt | sed 's/^[ \t]*/  /'

    # Show validity
    echo "📍 Validity:"
    echo "$CERT_INFO" | openssl x509 -noout -dates | sed 's/^/  /'

    # Check expiration
    EXPIRE_DATE=$(echo "$CERT_INFO" | openssl x509 -noout -enddate | cut -d= -f2)
    EXPIRE_EPOCH=$(date -d "$EXPIRE_DATE" +%s 2>/dev/null || date -j -f "%b %d %T %Y %Z" "$EXPIRE_DATE" +%s)
    CURRENT_EPOCH=$(date +%s)
    DAYS_LEFT=$(( ($EXPIRE_EPOCH - $CURRENT_EPOCH) / 86400 ))

    echo "📍 Days until expiration: $DAYS_LEFT"

    if [ $DAYS_LEFT -lt 30 ]; then
        echo "⚠️  WARNING: Certificate expires soon!"
    else
        echo "✅ Certificate is valid"
    fi

    # Check protocols
    echo ""
    echo "📍 Supported protocols:"
    for proto in tls1 tls1_1 tls1_2 tls1_3; do
        if echo | openssl s_client -connect $DOMAIN:$PORT -servername $DOMAIN -$proto 2>/dev/null | grep -q "Cipher is"; then
            echo "  ✅ ${proto^^} supported"
        else
            echo "  ❌ ${proto^^} not supported"
        fi
    done

    rm -f /tmp/cert.txt
else
    echo "❌ Could not connect to $DOMAIN:$PORT"
fi
EOF

chmod +x /usr/local/bin/check-ssl.sh

# Test it
check-ssl.sh localhost

🎮 Practice Exercise

Try different SSL configurations:

Create multiple sites with SSL
Test different cipher suites
Monitor certificate expiration
Set up SSL for subdomains

# Create test subdomain config
cat > /etc/nginx/conf.d/subdomain-ssl.conf << 'EOF'
server {
    listen 443 ssl http2;
    server_name sub.localhost;

    ssl_certificate /etc/nginx/ssl/server.crt;
    ssl_certificate_key /etc/nginx/ssl/server.key;

    root /var/www/subdomain;
    index index.html;
}
EOF

# Create subdomain directory
mkdir -p /var/www/subdomain
echo "<h1>Secure Subdomain</h1>" > /var/www/subdomain/index.html

# Reload and test
nginx -t && rc-service nginx reload

🚨 Troubleshooting Common Issues

Certificate Not Trusted

Fix trust issues:

# For self-signed certificates
# Browsers will show warning - this is normal

# Add to local trust store (for testing)
cp /etc/nginx/ssl/server.crt /usr/local/share/ca-certificates/
update-ca-certificates

# Check certificate chain
openssl verify -CAfile /etc/nginx/ssl/server.crt /etc/nginx/ssl/server.crt

Mixed Content Warnings

Fix HTTP resources on HTTPS pages:

# Find mixed content in files
grep -r "http://" /var/www/ | grep -v "https://"

# Update all HTTP links to HTTPS
find /var/www -type f -name "*.html" -exec \
  sed -i 's|http://|https://|g' {} \;

SSL Handshake Failed

Debug SSL handshake:

# Enable debug logging
sed -i 's/error_log.*;/error_log \/var\/log\/nginx\/error.log debug;/' \
  /etc/nginx/nginx.conf

# Reload and check logs
rc-service nginx reload
tail -f /var/log/nginx/error.log

# Test with verbose output
curl -v https://localhost -k

💡 Pro Tips

Tip 1: SSL Performance

Optimize SSL performance:

# Enable session cache
ssl_session_cache shared:SSL:50m;
ssl_session_timeout 1d;

# Enable keepalive
keepalive_timeout 70;
keepalive_requests 100;

Tip 2: Security Headers

Add comprehensive security headers:

# Security headers snippet
cat > /etc/nginx/snippets/security-headers.conf << 'EOF'
add_header X-Frame-Options "SAMEORIGIN" always;
add_header X-Content-Type-Options "nosniff" always;
add_header Referrer-Policy "no-referrer-when-downgrade" always;
add_header Content-Security-Policy "default-src 'self' http: https: data: blob: 'unsafe-inline'" always;
add_header Permissions-Policy "camera=(), microphone=(), geolocation=()" always;
EOF

# Include in server blocks
# include /etc/nginx/snippets/security-headers.conf;

Tip 3: Multi-Domain Certificates

Handle multiple domains:

# Get multi-domain certificate
certbot certonly --standalone \
  -d example.com \
  -d www.example.com \
  -d api.example.com \
  -d app.example.com

# Or use wildcard
certbot certonly --standalone \
  -d "*.example.com" \
  -d example.com \
  --preferred-challenges dns

✅ Best Practices

Use strong ciphers
- TLS 1.2 minimum
- Disable weak ciphers
- Regular updates

Certificate management

# Monthly check script
0 0 1 * * /usr/local/bin/check-ssl.sh

Monitor expiration

# Alert before expiry
certbot renew --dry-run

Backup certificates

# Backup SSL files
tar -czf ssl-backup-$(date +%Y%m%d).tar.gz /etc/nginx/ssl/

Test regularly

# Use SSL Labs test
# ssllabs.com/ssltest/

🏆 What You Learned

Great job! You can now:

✅ Generate SSL certificates
✅ Configure Nginx for HTTPS
✅ Set up Let’s Encrypt
✅ Optimize SSL settings
✅ Monitor certificate status

Your websites are now secure!

🎯 What’s Next?

Now that you have SSL/TLS, explore:

HTTP/2 and HTTP/3 setup
SSL certificate automation
Web Application Firewall
Advanced security headers

Keep securing the web! 🔒

🔒 Setting Up Nginx SSL/TLS: Simple Guide

Table of Contents

🤔 What is SSL/TLS?

🎯 What You Need

📋 Step 1: Install Required Tools

📋 Step 2: Create Self-Signed Certificate

📋 Step 3: Configure Nginx for SSL

📋 Step 4: Get Let’s Encrypt Certificate

📋 Step 5: Test SSL Configuration

📋 Step 6: Advanced SSL Settings

📋 Step 7: Monitor SSL Status

🎮 Practice Exercise

🚨 Troubleshooting Common Issues

Certificate Not Trusted

Mixed Content Warnings

SSL Handshake Failed

💡 Pro Tips

Tip 1: SSL Performance

Tip 2: Security Headers

Tip 3: Multi-Domain Certificates

✅ Best Practices

🏆 What You Learned

🎯 What’s Next?

Share this article

🔒 Setting Up Nginx SSL/TLS: Simple Guide

Table of Contents

🤔 What is SSL/TLS?

🎯 What You Need

📋 Step 1: Install Required Tools

📋 Step 2: Create Self-Signed Certificate

📋 Step 3: Configure Nginx for SSL

📋 Step 4: Get Let’s Encrypt Certificate

📋 Step 5: Test SSL Configuration

📋 Step 6: Advanced SSL Settings

📋 Step 7: Monitor SSL Status

🎮 Practice Exercise

🚨 Troubleshooting Common Issues

Certificate Not Trusted

Mixed Content Warnings

SSL Handshake Failed

💡 Pro Tips

Tip 1: SSL Performance

Tip 2: Security Headers

Tip 3: Multi-Domain Certificates

✅ Best Practices

🏆 What You Learned

🎯 What’s Next?

Share this article

Related Articles

📹 Configuring Video Streaming on Alpine Linux: Simple Guide

🛡️ Setting Up Disaster Recovery on Alpine Linux: Simple Guide

📊 Managing Log File Visualization on Alpine Linux: Simple Guide

Scan QR Code
