🌐 Configuring Network Routing: Simple Guide

Ready to set up network routing on Alpine Linux? This is exciting! 🎉 We’ll learn how to direct network traffic. Your computer will know where to send data! 😊

🤔 What is Network Routing?

Network routing tells your computer how to send data to other computers. Think of it like GPS for internet traffic!

Routing helps with:

• 🚦 Directing traffic to the right place
• 🔀 Choosing the best path for data
• 🌍 Connecting different networks together

🎯 What You Need

Before we start, you need:

• ✅ Alpine Linux system with network access
• ✅ Root access for network configuration
• ✅ Basic understanding of IP addresses
• ✅ Knowledge of your network setup

📋 Step 1: Understanding Current Routes

Viewing the Routing Table

Let’s see what routes your system already knows! This is the foundation! 😊

What we’re doing: Checking the current routing configuration.

# Show current routing table
route -n

# Alternative: using ip command
ip route show

# Show detailed route information
ip route show table all

# Check default gateway
ip route | grep default

What this does: 📖 Shows all the paths your computer knows for sending data.

Example output:

Kernel IP routing table
Destination     Gateway         Genmask         Flags Metric Ref    Use Iface
0.0.0.0         192.168.1.1     0.0.0.0         UG    0      0        0 eth0
192.168.1.0     0.0.0.0         255.255.255.0   U     0      0        0 eth0

What this means: Your computer knows how to reach the internet through 192.168.1.1! ✅

💡 Important Tips

Tip: Always backup your current routes before making changes! 💡

Warning: Wrong routes can break internet connectivity! ⚠️

🛠️ Step 2: Basic Route Configuration

Adding Static Routes

Now let’s add new routes! This directs traffic to specific destinations! 🎯

What we’re doing: Creating custom routes for specific networks.

# Add route to specific network
ip route add 10.0.0.0/24 via 192.168.1.10

# Add route through specific interface
ip route add 172.16.0.0/16 dev eth1

# Add default route
ip route add default via 192.168.1.1

# Add route with metric (priority)
ip route add 10.1.0.0/24 via 192.168.1.20 metric 100

Code explanation:

• 10.0.0.0/24: Network destination (IP range)
• via 192.168.1.10: Gateway to use for this route
• dev eth1: Interface to use directly
• metric 100: Route priority (lower numbers = higher priority)

Expected Output:

✅ Route to 10.0.0.0/24 added successfully
✅ Route via eth1 configured

What this means: Your computer now knows new paths to send data! 🌟

Deleting Routes

What we’re doing: Removing routes we don’t need anymore.

# Remove specific route
ip route del 10.0.0.0/24 via 192.168.1.10

# Remove route by destination only
ip route del 172.16.0.0/16

# Remove default route
ip route del default via 192.168.1.1

# Check routes after deletion
ip route show

What this does: Cleans up routing table by removing unused paths! 📚

📊 Quick Summary Table

🎮 Step 3: Advanced Routing Configuration

Setting Up Multiple Gateways

Let’s configure multiple internet connections! This is powerful! 🌟

What we’re doing: Setting up load balancing and failover between gateways.

# Install routing utilities
apk add iproute2 iptables

# Create routing tables
echo "200 wan1" >> /etc/iproute2/rt_tables
echo "201 wan2" >> /etc/iproute2/rt_tables

# Configure first gateway
ip route add default via 192.168.1.1 dev eth0 table wan1
ip rule add from 192.168.1.0/24 table wan1

# Configure second gateway
ip route add default via 192.168.2.1 dev eth1 table wan2
ip rule add from 192.168.2.0/24 table wan2

# Set up load balancing
ip route add default scope global \
    nexthop via 192.168.1.1 dev eth0 weight 1 \
    nexthop via 192.168.2.1 dev eth1 weight 1

What this does: Creates smart routing with multiple internet connections! 🚀

Policy-Based Routing

What we’re doing: Creating rules that route traffic based on specific criteria.

# Route traffic from specific source
ip rule add from 10.0.1.0/24 table wan1 priority 100

# Route traffic to specific destination
ip rule add to 8.8.8.8 table wan2 priority 200

# Route traffic based on port
iptables -t mangle -A OUTPUT -p tcp --dport 80 -j MARK --set-mark 1
ip rule add fwmark 1 table wan1 priority 300

# Create rules for different services
ip rule add from 192.168.1.100 table wan2 priority 150
ip rule add to 192.168.10.0/24 table wan1 priority 250

# Show all rules
ip rule show

Expected Output:

0:      from all lookup local
100:    from 10.0.1.0/24 lookup wan1
150:    from 192.168.1.100 lookup wan2
200:    to 8.8.8.8 lookup wan2
250:    to 192.168.10.0/24 lookup wan1
300:    from all fwmark 0x1 lookup wan1
32766:  from all lookup main
32767:  from all lookup default

What this means: Traffic follows smart rules based on source and destination! 🎉

🎮 Practice Time!

Let’s practice what you learned! Try these simple examples:

Example 1: Create Network Segments 🟢

What we’re doing: Setting up routing between different network segments.

# Create virtual interfaces for testing
ip link add veth0 type veth peer name veth1
ip link set veth0 up
ip link set veth1 up

# Assign IP addresses
ip addr add 10.1.1.1/24 dev veth0
ip addr add 10.2.2.1/24 dev veth1

# Create routes between segments
ip route add 10.1.1.0/24 dev veth0
ip route add 10.2.2.0/24 dev veth1

# Test connectivity
ping -c 3 10.1.1.1
ping -c 3 10.2.2.1

# Show routing table
ip route show | grep "10\."

echo "Network segments configured! ✅"

What this does: Creates separate network segments with proper routing! 🌟

Example 2: Configure Route Persistence 🟡

What we’re doing: Making routes survive system reboots.

# Create network configuration file
cat > /etc/network/interfaces << 'EOF'
# Alpine Linux network configuration
auto lo
iface lo inet loopback

auto eth0
iface eth0 inet static
    address 192.168.1.100
    netmask 255.255.255.0
    gateway 192.168.1.1
    up ip route add 10.0.0.0/8 via 192.168.1.10
    up ip route add 172.16.0.0/12 via 192.168.1.20
    down ip route del 10.0.0.0/8 via 192.168.1.10
    down ip route del 172.16.0.0/12 via 192.168.1.20
EOF

# Create custom routing script
cat > /etc/local.d/custom-routes.start << 'EOF'
#!/bin/sh
# Custom routing configuration

# Add static routes
ip route add 192.168.100.0/24 via 192.168.1.50
ip route add 192.168.200.0/24 via 192.168.1.60

# Configure policy routing
ip rule add from 192.168.1.0/24 table main priority 100
EOF

chmod +x /etc/local.d/custom-routes.start

# Enable local.d service
rc-update add local default

# Test configuration
/etc/local.d/custom-routes.start

echo "Persistent routing configured! 📚"

What this does: Ensures your routing configuration survives reboots! 📚

🚨 Fix Common Problems

Problem 1: Route not working ❌

What happened: Added route but traffic doesn’t flow. How to fix it: Check route details and connectivity!

# Verify route was added
ip route show | grep "your-destination"

# Test gateway connectivity
ping -c 3 192.168.1.1

# Check interface status
ip link show

# Verify IP forwarding is enabled
sysctl net.ipv4.ip_forward

# Enable IP forwarding if needed
echo "net.ipv4.ip_forward = 1" >> /etc/sysctl.conf
sysctl -p

Problem 2: Multiple routes conflict ❌

What happened: Different routes pointing to same destination. How to fix it: Check route priorities and remove conflicts!

# Show routes with metrics
ip route show | grep "your-destination"

# Remove conflicting route
ip route del conflicting-route

# Add route with specific metric
ip route add 10.0.0.0/24 via 192.168.1.10 metric 100

# Verify only one route exists
ip route show | grep "10.0.0.0/24"

Problem 3: Routes disappear after reboot ❌

What happened: Routes don’t persist after restart. How to fix it: Make configuration permanent!

# Check if networking service is enabled
rc-status | grep networking

# Create persistent route file
echo "ip route add 10.0.0.0/24 via 192.168.1.10" > /etc/conf.d/net.eth0

# Or add to interfaces file
echo "    up ip route add 10.0.0.0/24 via 192.168.1.10" >> /etc/network/interfaces

# Restart networking
rc-service networking restart

Don’t worry! Network routing takes practice. You’re doing great! 💪

💡 Simple Tips

1. Test carefully 📅 - Small changes first
2. Document routes 🌱 - Keep notes of what you add
3. Use metrics 🤝 - Set priorities properly
4. Monitor traffic 💪 - Watch what happens

✅ Check Everything Works

Let’s verify routing is working correctly:

# Check routing table
ip route show

# Test default gateway
ping -c 3 $(ip route | grep default | awk '{print $3}')

# Test internet connectivity
ping -c 3 8.8.8.8

# Check route to specific destination
traceroute 8.8.8.8

# Verify policy rules
ip rule show

# Test custom routes if configured
ping -c 3 10.0.0.1

echo "Network routing verification completed! ✅"

Good output:

default via 192.168.1.1 dev eth0
192.168.1.0/24 dev eth0 scope link
PING 192.168.1.1: 3 packets transmitted, 3 received
PING 8.8.8.8: 3 packets transmitted, 3 received
✅ Traceroute shows proper path
Network routing verification completed! ✅

🔧 Advanced Routing Features

Dynamic Routing with BIRD

Let’s set up dynamic routing for complex networks! This is professional! 🎯

What we’re doing: Installing and configuring BIRD routing daemon.

# Install BIRD routing daemon
apk add bird

# Create BIRD configuration
cat > /etc/bird.conf << 'EOF'
# BIRD Routing Daemon Configuration

# Router ID (use your main IP)
router id 192.168.1.100;

# Enable debugging
debug protocols all;

# Device protocol for interface discovery
protocol device {
    scan time 10;
}

# Direct protocol for directly connected networks
protocol direct {
    interface "*";
}

# Kernel protocol to sync with system routing table
protocol kernel {
    export all;
    scan time 20;
}

# Static routes
protocol static {
    route 10.0.0.0/8 via 192.168.1.10;
    route 172.16.0.0/12 via 192.168.1.20;
}

# OSPF protocol for dynamic routing
protocol ospf {
    area 0.0.0.0 {
        interface "eth0" {
            hello 10;
            dead count 5;
        };
    };
}
EOF

# Start BIRD daemon
rc-service bird start
rc-update add bird default

# Check BIRD status
birdc show protocols
birdc show route

What this does: Creates professional dynamic routing capabilities! 🌟

Network Monitoring and Troubleshooting

What we’re doing: Setting up tools to monitor and debug routing.

# Install network monitoring tools
apk add tcpdump wireshark-common mtr

# Create network monitoring script
cat > /usr/local/bin/network-monitor.sh << 'EOF'
#!/bin/sh
# Network Routing Monitor

LOG_FILE="/var/log/network-monitor.log"

log_message() {
    echo "$(date '+%Y-%m-%d %H:%M:%S'): $1" | tee -a "$LOG_FILE"
}

# Check routing table changes
check_routes() {
    local current_routes=$(ip route show | md5sum)
    local stored_routes="/tmp/last_routes.md5"

    if [ -f "$stored_routes" ]; then
        if [ "$current_routes" != "$(cat $stored_routes)" ]; then
            log_message "Routing table changed!"
            ip route show | tee -a "$LOG_FILE"
        fi
    fi

    echo "$current_routes" > "$stored_routes"
}

# Test gateway connectivity
test_gateways() {
    ip route | grep "^default" | while read route; do
        gateway=$(echo $route | awk '{print $3}')
        if ping -c 1 -W 2 "$gateway" >/dev/null 2>&1; then
            log_message "Gateway $gateway: OK"
        else
            log_message "Gateway $gateway: FAILED"
        fi
    done
}

# Monitor network interfaces
check_interfaces() {
    ip link show | grep "state DOWN" | while read line; do
        interface=$(echo $line | awk '{print $2}' | sed 's/:$//')
        log_message "Interface $interface is DOWN"
    done
}

# Run checks
log_message "=== Network monitoring started ==="
check_routes
test_gateways
check_interfaces
log_message "=== Network monitoring completed ==="
EOF

chmod +x /usr/local/bin/network-monitor.sh

# Set up monitoring cron job
echo "*/5 * * * * /usr/local/bin/network-monitor.sh" | crontab -

# Test monitoring
/usr/local/bin/network-monitor.sh

echo "Network monitoring configured! 📊"

Expected Output:

2025-06-03 18:45:01: === Network monitoring started ===
2025-06-03 18:45:01: Gateway 192.168.1.1: OK
2025-06-03 18:45:01: === Network monitoring completed ===
Network monitoring configured! 📊

What this means: You have professional network monitoring! 🎉

🏆 What You Learned

Great job! Now you can:

• ✅ View and understand routing tables
• ✅ Add and remove static routes
• ✅ Configure advanced routing with multiple gateways
• ✅ Set up persistent routing and monitoring!

🎯 What’s Next?

Now you can try:

• 📚 Learning about BGP routing for large networks
• 🛠️ Setting up VPN routing and tunnels
• 🤝 Implementing quality of service (QoS) routing
• 🌟 Building complex multi-homed network setups!

Remember: Every network engineer was once a beginner. You’re doing amazing! 🎉

Keep practicing and you’ll become an expert too! 💫
