📸 Managing File System Snapshots: Simple Guide

I’ll show you how to manage file system snapshots on Alpine Linux! Snapshots are like taking a photo of your files at a specific moment - you can go back to that exact state anytime. It’s perfect for backups, testing changes, or recovering from mistakes!

🤔 What are File System Snapshots?

A snapshot captures the state of your file system at a specific point in time. Unlike regular backups that copy files, snapshots are instant and use minimal space by only tracking changes. Think of it as a save point in a video game - you can always return to that exact moment!

Why use snapshots?

Instant backups
Easy rollback from mistakes
Test changes safely
Minimal storage usage
Quick recovery

🎯 What You Need

Before starting, you’ll need:

Alpine Linux installed
Storage space available
Root access
Compatible file system (Btrfs or LVM)
About 20 minutes

📋 Step 1: Choose Your Snapshot System

Alpine Linux supports multiple snapshot methods:

# Check current file system
df -T
mount | grep "^/dev"

# Option 1: Btrfs (Best for snapshots)
apk add btrfs-progs

# Option 2: LVM snapshots
apk add lvm2 lvm2-extra

# Option 3: ZFS (Advanced)
apk add zfs zfs-lts

# For this guide, we'll focus on Btrfs and LVM

📋 Step 2: Set Up Btrfs Snapshots

If using Btrfs file system:

# Check if using Btrfs
btrfs filesystem show

# Create snapshot directory
mkdir -p /snapshots

# Create your first snapshot
btrfs subvolume snapshot / /snapshots/root-$(date +%Y%m%d-%H%M%S)

# List snapshots
btrfs subvolume list /

# Create read-only snapshot (recommended)
btrfs subvolume snapshot -r / /snapshots/root-backup-$(date +%Y%m%d)

# Verify snapshot
ls -la /snapshots/

📋 Step 3: Set Up LVM Snapshots

For LVM-based systems:

# Check LVM setup
lvdisplay
vgdisplay

# Create snapshot of logical volume
# Syntax: lvcreate -L size -s -n snapshot_name /dev/vg/lv
lvcreate -L 1G -s -n root_snap_$(date +%Y%m%d) /dev/vg0/root

# List snapshots
lvs

# Mount snapshot to access files
mkdir -p /mnt/snapshot
mount /dev/vg0/root_snap_$(date +%Y%m%d) /mnt/snapshot

# Check snapshot usage
lvdisplay /dev/vg0/root_snap_*

📋 Step 4: Automate Snapshots

Create automatic snapshot system:

# Create snapshot script
cat > /usr/local/bin/auto-snapshot.sh << 'EOF'
#!/bin/sh
# Automatic snapshot creation

SNAPSHOT_DIR="/snapshots"
FILESYSTEM="/"
MAX_SNAPSHOTS=10
DATE=$(date +%Y%m%d-%H%M%S)

# Function for Btrfs snapshots
create_btrfs_snapshot() {
    echo "Creating Btrfs snapshot..."
    btrfs subvolume snapshot -r "$FILESYSTEM" "$SNAPSHOT_DIR/auto-$DATE"

    # Clean old snapshots
    SNAPSHOTS=$(ls -1 $SNAPSHOT_DIR/auto-* 2>/dev/null | sort -r)
    COUNT=$(echo "$SNAPSHOTS" | wc -l)

    if [ $COUNT -gt $MAX_SNAPSHOTS ]; then
        echo "Removing old snapshots..."
        echo "$SNAPSHOTS" | tail -n +$((MAX_SNAPSHOTS + 1)) | while read snap; do
            btrfs subvolume delete "$snap"
        done
    fi
}

# Function for LVM snapshots
create_lvm_snapshot() {
    VG="vg0"
    LV="root"
    SIZE="1G"

    echo "Creating LVM snapshot..."
    lvcreate -L $SIZE -s -n snap_$DATE /dev/$VG/$LV

    # Remove old snapshots
    OLD_SNAPS=$(lvs --noheadings -o lv_name | grep "^snap_" | sort | head -n -$MAX_SNAPSHOTS)
    for snap in $OLD_SNAPS; do
        echo "Removing old snapshot: $snap"
        lvremove -f /dev/$VG/$snap
    done
}

# Detect and run appropriate snapshot method
if btrfs filesystem show / >/dev/null 2>&1; then
    create_btrfs_snapshot
elif lvs >/dev/null 2>&1; then
    create_lvm_snapshot
else
    echo "No supported snapshot system found!"
    exit 1
fi

echo "Snapshot completed: $DATE"
EOF

chmod +x /usr/local/bin/auto-snapshot.sh

# Add to cron for hourly snapshots
echo "0 * * * * /usr/local/bin/auto-snapshot.sh" | crontab -

📋 Step 5: Manage Snapshots

Tools for snapshot management:

# Create snapshot manager
cat > /usr/local/bin/snapshot-manager.sh << 'EOF'
#!/bin/sh
# Snapshot Manager

show_menu() {
    echo "📸 Snapshot Manager"
    echo "=================="
    echo "1. List snapshots"
    echo "2. Create snapshot"
    echo "3. Delete snapshot"
    echo "4. Compare snapshots"
    echo "5. Restore from snapshot"
    echo "6. Snapshot info"
    echo "7. Exit"
}

list_snapshots() {
    echo -e "\n📋 Available Snapshots:"
    if btrfs filesystem show / >/dev/null 2>&1; then
        btrfs subvolume list / | grep snapshot
    else
        lvs | grep snap_
    fi
}

create_snapshot() {
    echo -n "Enter snapshot name: "
    read name

    if btrfs filesystem show / >/dev/null 2>&1; then
        btrfs subvolume snapshot -r / /snapshots/$name
    else
        lvcreate -L 1G -s -n $name /dev/vg0/root
    fi

    echo "✅ Snapshot created: $name"
}

delete_snapshot() {
    list_snapshots
    echo -n -e "\nEnter snapshot to delete: "
    read name

    if btrfs filesystem show / >/dev/null 2>&1; then
        btrfs subvolume delete /snapshots/$name
    else
        lvremove -f /dev/vg0/$name
    fi

    echo "✅ Snapshot deleted: $name"
}

compare_snapshots() {
    echo "Comparing snapshots..."
    # Add comparison logic here
}

restore_snapshot() {
    echo "⚠️  WARNING: This will restore system to snapshot state!"
    echo -n "Continue? (y/N): "
    read confirm

    if [ "$confirm" != "y" ]; then
        return
    fi

    # Add restore logic here
    echo "✅ Restore completed"
}

# Main loop
while true; do
    show_menu
    echo -n "Select option: "
    read choice

    case $choice in
        1) list_snapshots ;;
        2) create_snapshot ;;
        3) delete_snapshot ;;
        4) compare_snapshots ;;
        5) restore_snapshot ;;
        6) snapshot_info ;;
        7) exit 0 ;;
        *) echo "Invalid option" ;;
    esac

    echo -e "\nPress Enter to continue..."
    read
    clear
done
EOF

chmod +x /usr/local/bin/snapshot-manager.sh

📋 Step 6: Snapshot Best Practices

Implement smart snapshot policies:

# Create snapshot policy configuration
cat > /etc/snapshot-policy.conf << 'EOF'
# Snapshot Policy Configuration

# Retention settings
HOURLY_SNAPSHOTS=24
DAILY_SNAPSHOTS=7
WEEKLY_SNAPSHOTS=4
MONTHLY_SNAPSHOTS=12

# Paths to snapshot
SNAPSHOT_PATHS="/ /home /var"

# Exclude patterns
EXCLUDE_PATTERNS="/tmp /var/tmp /var/cache"

# Snapshot naming
SNAPSHOT_PREFIX="auto"
SNAPSHOT_TYPE="readonly"
EOF

# Advanced snapshot script
cat > /usr/local/bin/smart-snapshot.sh << 'EOF'
#!/bin/sh
# Smart snapshot management

source /etc/snapshot-policy.conf

# Create snapshot with metadata
create_snapshot() {
    local path=$1
    local type=$2
    local name="${SNAPSHOT_PREFIX}-${type}-$(date +%Y%m%d-%H%M%S)"

    echo "Creating $type snapshot of $path..."

    if btrfs filesystem show $path >/dev/null 2>&1; then
        if [ "$SNAPSHOT_TYPE" = "readonly" ]; then
            btrfs subvolume snapshot -r $path /snapshots/$name
        else
            btrfs subvolume snapshot $path /snapshots/$name
        fi

        # Add metadata
        echo "path=$path" > /snapshots/$name.meta
        echo "type=$type" >> /snapshots/$name.meta
        echo "date=$(date)" >> /snapshots/$name.meta
    fi
}

# Rotate snapshots based on policy
rotate_snapshots() {
    local type=$1
    local keep=$2

    echo "Rotating $type snapshots (keeping $keep)..."

    # List snapshots of this type
    SNAPS=$(ls -1 /snapshots/${SNAPSHOT_PREFIX}-${type}-* 2>/dev/null | sort -r)
    COUNT=$(echo "$SNAPS" | wc -l)

    if [ $COUNT -gt $keep ]; then
        echo "$SNAPS" | tail -n +$((keep + 1)) | while read snap; do
            echo "Removing old snapshot: $snap"
            btrfs subvolume delete "$snap"
            rm -f "${snap}.meta"
        done
    fi
}

# Main execution
HOUR=$(date +%H)
DAY=$(date +%d)
WEEKDAY=$(date +%w)

# Hourly snapshot
create_snapshot "/" "hourly"
rotate_snapshots "hourly" $HOURLY_SNAPSHOTS

# Daily snapshot at midnight
if [ "$HOUR" = "00" ]; then
    create_snapshot "/" "daily"
    rotate_snapshots "daily" $DAILY_SNAPSHOTS
fi

# Weekly snapshot on Sunday
if [ "$WEEKDAY" = "0" ] && [ "$HOUR" = "00" ]; then
    create_snapshot "/" "weekly"
    rotate_snapshots "weekly" $WEEKLY_SNAPSHOTS
fi

# Monthly snapshot on first day
if [ "$DAY" = "01" ] && [ "$HOUR" = "00" ]; then
    create_snapshot "/" "monthly"
    rotate_snapshots "monthly" $MONTHLY_SNAPSHOTS
fi
EOF

chmod +x /usr/local/bin/smart-snapshot.sh

# Update cron
crontab -l | grep -v auto-snapshot > /tmp/cron.tmp
echo "0 * * * * /usr/local/bin/smart-snapshot.sh" >> /tmp/cron.tmp
crontab /tmp/cron.tmp

📋 Step 7: Snapshot Recovery

Learn to restore from snapshots:

# Create recovery script
cat > /usr/local/bin/snapshot-recovery.sh << 'EOF'
#!/bin/sh
# Snapshot Recovery Tool

# List available snapshots
echo "📸 Available Snapshots for Recovery:"
echo "===================================="

if btrfs filesystem show / >/dev/null 2>&1; then
    # Btrfs recovery
    btrfs subvolume list / | grep snapshot | nl

    echo -e "\n📍 To recover a file:"
    echo "cp /snapshots/snapshot-name/path/to/file /path/to/destination"

    echo -e "\n📍 To rollback entire system:"
    echo "1. Boot from rescue media"
    echo "2. Mount root filesystem"
    echo "3. mv /mnt/root /mnt/root.old"
    echo "4. btrfs subvolume snapshot /mnt/snapshots/snapshot-name /mnt/root"
else
    # LVM recovery
    lvs | grep snap_ | nl

    echo -e "\n📍 To recover files from LVM snapshot:"
    echo "1. mount /dev/vg0/snapshot-name /mnt/recovery"
    echo "2. cp /mnt/recovery/path/to/file /path/to/destination"
    echo "3. umount /mnt/recovery"
fi

# Interactive recovery
echo -e "\n🔄 Interactive Recovery"
echo -n "Enter snapshot name to browse: "
read snapshot

if [ -n "$snapshot" ]; then
    MOUNT_POINT="/mnt/snapshot-recovery"
    mkdir -p $MOUNT_POINT

    if btrfs filesystem show / >/dev/null 2>&1; then
        # Browse Btrfs snapshot
        echo "Snapshot contents:"
        ls -la /snapshots/$snapshot/
    else
        # Mount LVM snapshot
        mount /dev/vg0/$snapshot $MOUNT_POINT
        echo "Snapshot mounted at: $MOUNT_POINT"
        echo "Browse with: cd $MOUNT_POINT"
    fi
fi
EOF

chmod +x /usr/local/bin/snapshot-recovery.sh

📋 Step 8: Monitor Snapshot Usage

Track snapshot space usage:

# Create monitoring script
cat > /usr/local/bin/snapshot-monitor.sh << 'EOF'
#!/bin/sh
# Monitor snapshot usage

echo "📊 Snapshot Usage Report"
echo "======================="
echo ""

# Btrfs snapshots
if btrfs filesystem show / >/dev/null 2>&1; then
    echo "📁 Btrfs Snapshots:"

    # Overall usage
    echo "Total filesystem usage:"
    btrfs filesystem df /

    echo -e "\n📸 Snapshot sizes:"
    for snap in /snapshots/*; do
        if [ -d "$snap" ]; then
            SIZE=$(btrfs filesystem du -s $snap 2>/dev/null | tail -1 | awk '{print $2}')
            echo "  $(basename $snap): $SIZE"
        fi
    done
fi

# LVM snapshots
if lvs >/dev/null 2>&1; then
    echo -e "\n📁 LVM Snapshots:"

    # Show snapshot usage
    lvs -o lv_name,lv_size,data_percent,snap_percent | grep snap_

    # Warning for full snapshots
    FULL_SNAPS=$(lvs --noheadings -o lv_name,snap_percent | grep snap_ | \
                 awk '$2 > 80 {print $1}')

    if [ -n "$FULL_SNAPS" ]; then
        echo -e "\n⚠️  WARNING: Snapshots near capacity:"
        echo "$FULL_SNAPS"
    fi
fi

# Disk space check
echo -e "\n💾 Overall Disk Usage:"
df -h | grep -E "^/dev|^Filesystem"

# Snapshot count
echo -e "\n📈 Snapshot Statistics:"
if btrfs filesystem show / >/dev/null 2>&1; then
    TOTAL=$(ls -1 /snapshots/ 2>/dev/null | wc -l)
    HOURLY=$(ls -1 /snapshots/auto-hourly-* 2>/dev/null | wc -l)
    DAILY=$(ls -1 /snapshots/auto-daily-* 2>/dev/null | wc -l)
    WEEKLY=$(ls -1 /snapshots/auto-weekly-* 2>/dev/null | wc -l)
    MONTHLY=$(ls -1 /snapshots/auto-monthly-* 2>/dev/null | wc -l)

    echo "  Total snapshots: $TOTAL"
    echo "  Hourly: $HOURLY"
    echo "  Daily: $DAILY"
    echo "  Weekly: $WEEKLY"
    echo "  Monthly: $MONTHLY"
fi
EOF

chmod +x /usr/local/bin/snapshot-monitor.sh

# Add monitoring to cron
echo "0 6 * * * /usr/local/bin/snapshot-monitor.sh | mail -s 'Snapshot Report' [email protected]" | crontab -

🎮 Practice Exercise

Try managing snapshots:

Create a test directory
Take a snapshot
Modify files
Restore from snapshot

# Create test environment
mkdir -p /test-data
echo "Original content" > /test-data/file1.txt
echo "Important data" > /test-data/file2.txt

# Take snapshot
btrfs subvolume snapshot -r / /snapshots/before-test

# Modify files
echo "Modified content" > /test-data/file1.txt
rm /test-data/file2.txt

# Check differences
diff /test-data/file1.txt /snapshots/before-test/test-data/file1.txt

# Restore files
cp /snapshots/before-test/test-data/* /test-data/

# Verify restoration
cat /test-data/file1.txt
cat /test-data/file2.txt

🚨 Troubleshooting Common Issues

Snapshot Full

Handle full snapshots:

# Check LVM snapshot usage
lvdisplay | grep -A10 "snap_"

# Extend snapshot size
lvextend -L +1G /dev/vg0/snap_name

# Or merge and recreate
lvconvert --merge /dev/vg0/snap_name
lvcreate -L 2G -s -n new_snap /dev/vg0/root

Cannot Delete Snapshot

Fix deletion issues:

# Btrfs snapshot busy
lsof | grep /snapshots/snapshot-name
fuser -vm /snapshots/snapshot-name

# Force unmount
umount -f /snapshots/snapshot-name

# Delete read-only snapshot
btrfs property set /snapshots/snapshot-name ro false
btrfs subvolume delete /snapshots/snapshot-name

Performance Impact

Minimize snapshot overhead:

# Limit snapshot count
MAX_SNAPSHOTS=5

# Use read-only snapshots
btrfs subvolume snapshot -r / /snapshots/name

# Monitor performance
iostat -x 1

💡 Pro Tips

Tip 1: Snapshot Before Updates

Always snapshot before changes:

# Pre-update snapshot
cat > /usr/local/bin/pre-update-snapshot.sh << 'EOF'
#!/bin/sh
echo "Creating pre-update snapshot..."
/usr/local/bin/auto-snapshot.sh
echo "Snapshot created. Proceeding with update..."
apk upgrade
EOF

chmod +x /usr/local/bin/pre-update-snapshot.sh

Tip 2: Remote Snapshots

Send snapshots to backup server:

# Send Btrfs snapshot
btrfs send /snapshots/snapshot-name | \
    ssh backup@server "btrfs receive /backups/"

# Incremental send
btrfs send -p /snapshots/previous /snapshots/current | \
    ssh backup@server "btrfs receive /backups/"

Tip 3: Snapshot Verification

Verify snapshot integrity:

# Check snapshot health
btrfs scrub start /snapshots/
btrfs scrub status /snapshots/

# Compare checksums
find /snapshots/snapshot-name -type f -exec md5sum {} \; > snapshot.md5
md5sum -c snapshot.md5

✅ Best Practices

Regular snapshots

# Hourly for active systems
# Daily for stable systems

Test recovery procedures

# Practice restoration monthly
# Document recovery steps

Monitor space usage

# Set up alerts for full snapshots
# Clean old snapshots automatically

Use descriptive names

# Good: before-kernel-upgrade-5.15
# Bad: snapshot1

Secure snapshots

# Read-only snapshots
# Restrict access permissions

🏆 What You Learned

Fantastic work! You can now:

✅ Create file system snapshots
✅ Automate snapshot creation
✅ Manage snapshot retention
✅ Restore files from snapshots
✅ Monitor snapshot usage

Your data is now protected with snapshots!

🎯 What’s Next?

Now that you understand snapshots, explore:

Incremental backup strategies
Snapshot replication
Disaster recovery planning
Advanced Btrfs/ZFS features

Keep your data safe! 📸

📸 Managing File System Snapshots: Simple Guide

Table of Contents

🤔 What are File System Snapshots?

🎯 What You Need

📋 Step 1: Choose Your Snapshot System

📋 Step 2: Set Up Btrfs Snapshots

📋 Step 3: Set Up LVM Snapshots

📋 Step 4: Automate Snapshots

📋 Step 5: Manage Snapshots

📋 Step 6: Snapshot Best Practices

📋 Step 7: Snapshot Recovery

📋 Step 8: Monitor Snapshot Usage

🎮 Practice Exercise

🚨 Troubleshooting Common Issues

Snapshot Full

Cannot Delete Snapshot

Performance Impact

💡 Pro Tips

Tip 1: Snapshot Before Updates

Tip 2: Remote Snapshots

Tip 3: Snapshot Verification

✅ Best Practices

🏆 What You Learned

🎯 What’s Next?

Share this article

📸 Managing File System Snapshots: Simple Guide

Table of Contents

🤔 What are File System Snapshots?

🎯 What You Need

📋 Step 1: Choose Your Snapshot System

📋 Step 2: Set Up Btrfs Snapshots

📋 Step 3: Set Up LVM Snapshots

📋 Step 4: Automate Snapshots

📋 Step 5: Manage Snapshots

📋 Step 6: Snapshot Best Practices

📋 Step 7: Snapshot Recovery

📋 Step 8: Monitor Snapshot Usage

🎮 Practice Exercise

🚨 Troubleshooting Common Issues

Snapshot Full

Cannot Delete Snapshot

Performance Impact

💡 Pro Tips

Tip 1: Snapshot Before Updates

Tip 2: Remote Snapshots

Tip 3: Snapshot Verification

✅ Best Practices

🏆 What You Learned

🎯 What’s Next?

Share this article

Related Articles

📊 Monitoring File System Usage: Simple Guide

🗂️ Installing File System Utilities: Simple Guide

⚡ Tuning Disk I/O Performance: Simple Guide

Scan QR Code
