Deploying Time-Series Database with InfluxDB and Telegraf on AlmaLinux

Time-series databases have become essential for modern infrastructure monitoring, IoT data collection, and real-time analytics. This guide demonstrates deploying a production-ready InfluxDB 2.0 cluster with Telegraf collectors on AlmaLinux, covering everything from installation to advanced optimization techniques.

Understanding Time-Series Data Architecture

Time-series databases are optimized for handling time-stamped data with these characteristics:

• High write throughput: Millions of data points per second
• Efficient compression: Specialized algorithms for time-series data
• Fast aggregation queries: Built-in functions for time-based analysis
• Automatic data retention: Age-based data lifecycle management
• Real-time processing: Stream processing capabilities

InfluxDB 2.0 Architecture

Key components include:

1. Storage Engine: TSM (Time-Structured Merge Tree)
2. Query Engine: Flux language for powerful data analysis
3. Task Engine: Automated data processing
4. API Layer: RESTful API and client libraries
5. UI Dashboard: Built-in visualization and management

Prerequisites

Before deploying InfluxDB and Telegraf:

• AlmaLinux 9 server with 8GB+ RAM
• SSD storage (recommended for performance)
• Network connectivity for data sources
• Basic understanding of time-series concepts
• SSL certificates for secure endpoints

Installing InfluxDB 2.0

System Preparation

# Update system packages
sudo dnf update -y

# Install required dependencies
sudo dnf install -y wget curl gnupg2

# Configure system limits for InfluxDB
cat <<EOF | sudo tee /etc/security/limits.d/influxdb.conf
influxdb soft nofile 65536
influxdb hard nofile 65536
influxdb soft nproc 32768
influxdb hard nproc 32768
EOF

# Configure kernel parameters
cat <<EOF | sudo tee /etc/sysctl.d/99-influxdb.conf
vm.swappiness = 1
vm.max_map_count = 262144
net.core.rmem_max = 134217728
net.core.wmem_max = 134217728
net.core.rmem_default = 134217728
net.core.wmem_default = 134217728
net.ipv4.tcp_rmem = 4096 87380 134217728
net.ipv4.tcp_wmem = 4096 65536 134217728
EOF

sudo sysctl -p /etc/sysctl.d/99-influxdb.conf

InfluxDB Installation

# Add InfluxDB repository
cat <<EOF | sudo tee /etc/yum.repos.d/influxdb.repo
[influxdb]
name = InfluxDB Repository - RHEL
baseurl = https://repos.influxdata.com/rhel/9/x86_64/stable
enabled = 1
gpgcheck = 1
gpgkey = https://repos.influxdata.com/influxdata-archive_compat.key
EOF

# Install InfluxDB
sudo dnf install -y influxdb2 influxdb2-cli

# Enable and start service
sudo systemctl enable influxdb
sudo systemctl start influxdb

# Verify installation
influx version

Initial Setup and Configuration

# Setup InfluxDB with initial user and organization
influx setup \
  --org my-org \
  --bucket metrics \
  --username admin \
  --password SecurePassword123! \
  --token my-super-secret-auth-token \
  --force

# Configure InfluxDB
sudo tee /etc/influxdb/config.toml <<EOF
# InfluxDB 2.0 Configuration

[meta]
  dir = "/var/lib/influxdb/meta"

[data]
  dir = "/var/lib/influxdb/data"
  wal-dir = "/var/lib/influxdb/wal"

  # Compaction settings
  compact-full-write-cold-duration = "4h"
  max-concurrent-compactions = 2

  # Cache settings
  cache-max-memory-size = "2g"
  cache-snapshot-memory-size = "256m"

[http]
  bind-address = ":8086"
  auth-enabled = true
  log-enabled = true
  write-tracing = false
  https-enabled = true
  https-certificate = "/etc/influxdb/cert.pem"
  https-private-key = "/etc/influxdb/key.pem"

  # Rate limiting
  rate-limit = 1000
  burst-limit = 10000

  # CORS
  access-control-allow-origin = "*"
  access-control-allow-methods = "GET, POST, PUT, DELETE, OPTIONS"

[storage-engine]
  # TSM engine settings
  cache-max-memory-size = "1g"
  cache-snapshot-memory-size = "25m"
  compact-throughput = "48m"
  max-concurrent-compactions = 3

[coordinator]
  write-timeout = "10s"
  max-concurrent-queries = 0
  query-timeout = "0s"
  max-select-point = 0
  max-select-series = 0
  max-select-buckets = 0

[retention]
  check-interval = "30m"
EOF

# Restart with new configuration
sudo systemctl restart influxdb

Setting Up SSL/TLS Security

# Generate self-signed certificate (for testing)
sudo mkdir -p /etc/influxdb/ssl
cd /etc/influxdb/ssl

sudo openssl req -x509 -nodes -days 365 -newkey rsa:2048 \
  -keyout /etc/influxdb/key.pem \
  -out /etc/influxdb/cert.pem \
  -subj "/C=US/ST=State/L=City/O=Organization/CN=influxdb.example.com"

# Set proper permissions
sudo chown influxdb:influxdb /etc/influxdb/*.pem
sudo chmod 600 /etc/influxdb/key.pem
sudo chmod 644 /etc/influxdb/cert.pem

# Configure firewall
sudo firewall-cmd --permanent --add-port=8086/tcp
sudo firewall-cmd --reload

Installing and Configuring Telegraf

Telegraf Installation

# Install Telegraf from InfluxDB repository
sudo dnf install -y telegraf

# Create base configuration
telegraf config > /etc/telegraf/telegraf.conf

# Enable and start Telegraf
sudo systemctl enable telegraf
sudo systemctl start telegraf

Comprehensive Telegraf Configuration

# /etc/telegraf/telegraf.conf
[global_tags]
  datacenter = "dc1"
  environment = "production"
  region = "us-east"

[agent]
  interval = "10s"
  round_interval = true
  metric_batch_size = 5000
  metric_buffer_limit = 50000
  collection_jitter = "0s"
  flush_interval = "10s"
  flush_jitter = "0s"
  precision = "0s"
  hostname = ""
  omit_hostname = false
  debug = false
  quiet = false

# Output to InfluxDB v2
[[outputs.influxdb_v2]]
  urls = ["https://localhost:8086"]
  token = "my-super-secret-auth-token"
  organization = "my-org"
  bucket = "metrics"

  ## Optional SSL Config
  insecure_skip_verify = false

  ## Timeout settings
  timeout = "5s"

  ## Batching
  metric_batch_size = 5000
  metric_buffer_limit = 50000

# System metrics collection
[[inputs.cpu]]
  percpu = true
  totalcpu = true
  collect_cpu_time = false
  report_active = false

[[inputs.disk]]
  ignore_fs = ["tmpfs", "devtmpfs", "devfs", "iso9660", "overlay", "aufs", "squashfs"]

[[inputs.diskio]]
  skip_serial_number = false
  device_tags = ["ID_FS_TYPE", "ID_FS_USAGE"]

[[inputs.kernel]]
  # no configuration

[[inputs.mem]]
  # no configuration

[[inputs.net]]
  interfaces = ["eth*", "eno*"]
  ignore_protocol_stats = false

[[inputs.processes]]
  # no configuration

[[inputs.swap]]
  # no configuration

[[inputs.system]]
  # no configuration

# Docker monitoring
[[inputs.docker]]
  endpoint = "unix:///var/run/docker.sock"
  gather_services = false
  container_names = []
  source_tag = false
  container_name_include = []
  container_name_exclude = []
  timeout = "5s"
  perdevice = true
  total = false

# Network monitoring
[[inputs.ping]]
  urls = ["google.com", "1.1.1.1", "8.8.8.8"]
  count = 3
  ping_interval = 1.0
  timeout = 1.0
  deadline = 10

# HTTP endpoint monitoring
[[inputs.http_response]]
  address = "https://example.com"
  response_timeout = "5s"
  method = "GET"
  follow_redirects = false
  response_status_code = 200

# Custom application metrics
[[inputs.prometheus]]
  urls = ["http://localhost:9090/metrics"]
  metric_version = 2
  response_timeout = "5s"

# Log parsing
[[inputs.tail]]
  files = ["/var/log/nginx/access.log"]
  from_beginning = false
  watch_method = "inotify"

  # Grok parsing
  grok_patterns = ["%{COMBINED_LOG_FORMAT}"]
  data_format = "grok"

  # Add custom tags
  [inputs.tail.tags]
    logtype = "nginx_access"

# SNMP monitoring
[[inputs.snmp]]
  agents = ["udp://192.168.1.1:161"]
  version = 2
  community = "public"

  [[inputs.snmp.field]]
    name = "hostname"
    oid = "RFC1213-MIB::sysName.0"

  [[inputs.snmp.field]]
    name = "uptime"
    oid = "RFC1213-MIB::sysUpTime.0"

Creating Custom Telegraf Plugins

Custom Exec Plugin

# Create custom metric collection script
sudo tee /usr/local/bin/custom_metrics.sh <<'EOF'
#!/bin/bash

# Collect custom application metrics
app_connections=$(ss -tan | grep :8080 | wc -l)
app_memory=$(ps aux | grep myapp | awk '{sum+=$6} END {print sum}')
app_cpu=$(ps aux | grep myapp | awk '{sum+=$3} END {print sum}')

# Output in InfluxDB line protocol format
echo "custom_app,host=$(hostname) connections=${app_connections}i,memory=${app_memory}i,cpu=${app_cpu}"
EOF

sudo chmod +x /usr/local/bin/custom_metrics.sh

# Add to Telegraf configuration
cat <<EOF | sudo tee -a /etc/telegraf/telegraf.conf

[[inputs.exec]]
  commands = ["/usr/local/bin/custom_metrics.sh"]
  timeout = "5s"
  data_format = "influx"
  interval = "30s"
EOF

Setting Up Data Retention Policies

Creating Retention Policies with Flux

# Create retention policy for different data types
influx bucket create \
  --name metrics-1d \
  --org my-org \
  --retention 1d

influx bucket create \
  --name metrics-7d \
  --org my-org \
  --retention 7d

influx bucket create \
  --name metrics-30d \
  --org my-org \
  --retention 30d

influx bucket create \
  --name metrics-1y \
  --org my-org \
  --retention 365d

Automated Downsampling Task

// Create downsampling task
option task = {
  name: "downsample-cpu-metrics",
  every: 1h,
}

from(bucket: "metrics")
  |> range(start: -1h)
  |> filter(fn: (r) => r._measurement == "cpu")
  |> aggregateWindow(every: 1m, fn: mean, createEmpty: false)
  |> to(bucket: "metrics-7d", org: "my-org")

Advanced Flux Queries

Complex Analytics Query

// Calculate 95th percentile response time by service
from(bucket: "metrics")
  |> range(start: -1h)
  |> filter(fn: (r) => r._measurement == "http_response_time")
  |> group(columns: ["service"])
  |> aggregateWindow(every: 5m, fn: (column, tables=<-) =>
      tables
      |> quantile(q: 0.95, column: column)
    )
  |> yield(name: "p95_response_time")

// Anomaly detection using moving average
from(bucket: "metrics")
  |> range(start: -24h)
  |> filter(fn: (r) => r._measurement == "cpu" and r._field == "usage_idle")
  |> movingAverage(n: 10)
  |> map(fn: (r) => ({
      r with
      anomaly: if r._value < r.moving_average - 20.0 then true else false
    }))
  |> filter(fn: (r) => r.anomaly == true)

Creating Alerts

// Alert task for high CPU usage
option task = {
  name: "cpu-alert",
  every: 1m,
}

from(bucket: "metrics")
  |> range(start: -5m)
  |> filter(fn: (r) => r._measurement == "cpu" and r._field == "usage_idle")
  |> aggregateWindow(every: 1m, fn: mean)
  |> map(fn: (r) => ({r with _value: 100.0 - r._value}))
  |> filter(fn: (r) => r._value > 80.0)
  |> each(fn: (r) =>
      sendAlert(
        url: "https://webhook.site/your-webhook",
        headers: {"Content-Type": "application/json"},
        data: {
          "alert": "High CPU Usage",
          "host": r.host,
          "value": r._value,
          "time": r._time
        }
      )
    )

Performance Optimization

Storage Optimization

# Configure optimal storage settings
sudo tee /etc/influxdb/storage-config.toml <<EOF
[storage]
  # WAL settings
  wal-fsync-delay = "100ms"
  max-concurrent-writes = 10

  # Compaction settings
  compact-full-write-cold-duration = "4h"
  compact-throughput = "48m"
  compact-throughput-burst = "96m"

  # Series cardinality limit
  max-series-per-database = 1000000
  max-values-per-tag = 100000

  # Cache settings
  cache-max-memory-size = "2g"
  cache-snapshot-memory-size = "256m"
  cache-snapshot-write-cold-duration = "10m"
EOF

# Monitor storage performance
cat <<'EOF' | sudo tee /usr/local/bin/monitor-influx-storage.sh
#!/bin/bash

# Check TSM file sizes
echo "TSM File Analysis:"
find /var/lib/influxdb/data -name "*.tsm" -type f -exec ls -lh {} \; | \
  awk '{size=$5; total+=size; count++} END {print "Total TSM files:", count, "Total size:", total}'

# Check compaction queue
echo -e "\nCompaction Status:"
influx query 'from(bucket: "_monitoring")
  |> range(start: -1h)
  |> filter(fn: (r) => r._measurement == "storage_compactions_queued")
  |> last()'

# Check write throughput
echo -e "\nWrite Performance:"
influx query 'from(bucket: "_monitoring")
  |> range(start: -1h)
  |> filter(fn: (r) => r._measurement == "storage_write_ok")
  |> aggregateWindow(every: 1m, fn: rate)'
EOF

sudo chmod +x /usr/local/bin/monitor-influx-storage.sh

Query Performance Tuning

# /etc/influxdb/query-config.toml
[query]
  # Query limits
  max-memory-bytes = 0
  queue-size = 1024
  max-concurrent-queries = 1024

  # Query timeout
  query-timeout = "60s"

  # Log slow queries
  log-queries-after = "5s"

  # Index settings
  max-select-point = 0
  max-select-series = 0
  max-select-buckets = 0

High Availability Setup

InfluxDB Clustering (Enterprise)

# influxdb-cluster.yaml
# Note: Clustering requires InfluxDB Enterprise
cluster:
  meta-nodes:
    - influx-meta-1:8091
    - influx-meta-2:8091
    - influx-meta-3:8091

  data-nodes:
    - influx-data-1:8088
    - influx-data-2:8088
    - influx-data-3:8088
    - influx-data-4:8088

  replication-factor: 2

  # Anti-entropy settings
  anti-entropy:
    enabled: true
    check-interval: "30s"
    max-fetch: 10

Load Balancing with HAProxy

# Install HAProxy
sudo dnf install -y haproxy

# Configure HAProxy for InfluxDB
sudo tee /etc/haproxy/haproxy.cfg <<EOF
global
    log         127.0.0.1 local0
    chroot      /var/lib/haproxy
    pidfile     /var/run/haproxy.pid
    maxconn     4000
    user        haproxy
    group       haproxy
    daemon

defaults
    mode                    tcp
    log                     global
    option                  tcplog
    option                  dontlognull
    option                  redispatch
    retries                 3
    timeout queue           1m
    timeout connect         10s
    timeout client          1m
    timeout server          1m
    timeout check           10s

frontend influxdb_write
    bind *:8086
    default_backend influxdb_write_backend

backend influxdb_write_backend
    balance roundrobin
    option httpchk GET /health
    server influx1 192.168.1.10:8086 check
    server influx2 192.168.1.11:8086 check
    server influx3 192.168.1.12:8086 check

frontend influxdb_query
    bind *:8087
    default_backend influxdb_query_backend

backend influxdb_query_backend
    balance leastconn
    option httpchk GET /health
    server influx1 192.168.1.10:8086 check
    server influx2 192.168.1.11:8086 check
    server influx3 192.168.1.12:8086 check
EOF

# Start HAProxy
sudo systemctl enable haproxy
sudo systemctl start haproxy

Integration with Visualization Tools

Grafana Integration

# Install Grafana
sudo dnf install -y grafana

# Configure Grafana data source
cat <<EOF | sudo tee /etc/grafana/provisioning/datasources/influxdb.yaml
apiVersion: 1

datasources:
  - name: InfluxDB
    type: influxdb
    access: proxy
    url: https://localhost:8086
    jsonData:
      version: Flux
      organization: my-org
      defaultBucket: metrics
      tlsSkipVerify: true
    secureJsonData:
      token: my-super-secret-auth-token
EOF

# Start Grafana
sudo systemctl enable grafana-server
sudo systemctl start grafana-server

Creating Dashboards with Flux

{
  "dashboard": {
    "title": "System Metrics Dashboard",
    "panels": [
      {
        "title": "CPU Usage",
        "targets": [
          {
            "query": "from(bucket: \"metrics\")\n  |> range(start: -1h)\n  |> filter(fn: (r) => r._measurement == \"cpu\" and r._field == \"usage_idle\")\n  |> map(fn: (r) => ({r with _value: 100.0 - r._value}))\n  |> aggregateWindow(every: 1m, fn: mean)"
          }
        ]
      },
      {
        "title": "Memory Usage",
        "targets": [
          {
            "query": "from(bucket: \"metrics\")\n  |> range(start: -1h)\n  |> filter(fn: (r) => r._measurement == \"mem\" and r._field == \"used_percent\")\n  |> aggregateWindow(every: 1m, fn: mean)"
          }
        ]
      }
    ]
  }
}

Monitoring and Maintenance

Automated Backup Script

#!/bin/bash
# /usr/local/bin/backup-influxdb.sh

BACKUP_DIR="/backup/influxdb"
RETENTION_DAYS=7
DATE=$(date +%Y%m%d_%H%M%S)

# Create backup directory
mkdir -p ${BACKUP_DIR}

# Backup InfluxDB
influx backup ${BACKUP_DIR}/backup_${DATE} \
  --token my-super-secret-auth-token

# Compress backup
tar -czf ${BACKUP_DIR}/backup_${DATE}.tar.gz \
  -C ${BACKUP_DIR} backup_${DATE}

# Remove uncompressed backup
rm -rf ${BACKUP_DIR}/backup_${DATE}

# Clean old backups
find ${BACKUP_DIR} -name "backup_*.tar.gz" -mtime +${RETENTION_DAYS} -delete

# Verify backup
if [ -f ${BACKUP_DIR}/backup_${DATE}.tar.gz ]; then
    echo "Backup completed successfully: backup_${DATE}.tar.gz"
else
    echo "Backup failed!" >&2
    exit 1
fi

Health Monitoring

# Create health check script
cat <<'EOF' | sudo tee /usr/local/bin/check-influxdb-health.sh
#!/bin/bash

# Check InfluxDB service
if ! systemctl is-active --quiet influxdb; then
    echo "CRITICAL: InfluxDB service is not running"
    exit 2
fi

# Check API endpoint
if ! curl -s -k https://localhost:8086/health | grep -q '"status":"pass"'; then
    echo "CRITICAL: InfluxDB API health check failed"
    exit 2
fi

# Check disk space
DISK_USAGE=$(df -h /var/lib/influxdb | awk 'NR==2 {print $5}' | sed 's/%//')
if [ $DISK_USAGE -gt 80 ]; then
    echo "WARNING: Disk usage is ${DISK_USAGE}%"
    exit 1
fi

echo "OK: InfluxDB is healthy"
exit 0
EOF

sudo chmod +x /usr/local/bin/check-influxdb-health.sh

# Add to crontab
echo "*/5 * * * * /usr/local/bin/check-influxdb-health.sh" | sudo crontab -

Conclusion

Deploying InfluxDB and Telegraf on AlmaLinux creates a powerful time-series data platform capable of handling millions of metrics per second. With proper configuration, retention policies, and monitoring, this setup provides a robust foundation for infrastructure monitoring, IoT data collection, and real-time analytics.

The combination of InfluxDB’s efficient storage engine, Flux’s powerful query language, and Telegraf’s extensive plugin ecosystem makes this solution ideal for organizations requiring comprehensive time-series data management at scale.
