☸️ AlmaLinux Kubernetes Cluster: Complete K8s Deployment Guide

Welcome to the exciting world of Kubernetes on AlmaLinux! 🚀 Whether you’re orchestrating microservices, scaling applications globally, or building cloud-native infrastructure, this comprehensive guide will transform you into a Kubernetes master who can deploy and manage production-grade clusters! 🎯

Kubernetes is the operating system of the cloud, and with AlmaLinux as your foundation, you’ll be running containerized applications at massive scale with automatic healing, scaling, and zero-downtime deployments! Let’s conquer container orchestration! 💪

🤔 Why is Kubernetes Important?

Kubernetes is like having an army of robots managing your applications 24/7! 🤖 Here’s why mastering K8s on AlmaLinux is absolutely essential:

• 🚀 Automatic Scaling - Scale from 1 to 1000s of containers instantly
• 🔄 Self-Healing - Automatic container restart and rescheduling
• 🌍 Service Discovery - Built-in DNS and load balancing
• 📦 Rolling Updates - Zero-downtime deployments
• 💾 Storage Orchestration - Automatic storage provisioning
• 🔐 Secret Management - Secure configuration and credentials
• 🎯 Resource Optimization - Efficient hardware utilization
• ☁️ Cloud Agnostic - Run anywhere from laptop to cloud

🎯 What You Need

Let’s prepare your environment for Kubernetes excellence! ✅

Hardware Requirements (Minimum):

• ✅ Master Node: 2 CPUs, 2GB RAM, 20GB disk
• ✅ Worker Nodes: 2 CPUs, 2GB RAM, 20GB disk each
• ✅ At least 3 nodes total (1 master, 2 workers)
• ✅ AlmaLinux 8.x or 9.x on all nodes
• ✅ Static IP addresses for all nodes

Network Requirements:

• ✅ Full network connectivity between all nodes
• ✅ Unique hostname, MAC address, and product_uuid
• ✅ Swap disabled on all nodes
• ✅ Ports 6443, 2379-2380, 10250-10252 open

📝 Preparing AlmaLinux for Kubernetes

Let’s prepare all nodes for Kubernetes installation! 🔧

System Preparation (All Nodes)

# Set hostname (unique for each node)
sudo hostnamectl set-hostname master.k8s.local  # Or worker1.k8s.local, etc.

# Update hosts file on all nodes
sudo tee -a /etc/hosts << 'EOF'
192.168.1.10 master.k8s.local master
192.168.1.11 worker1.k8s.local worker1
192.168.1.12 worker2.k8s.local worker2
EOF

# Disable swap
sudo swapoff -a
sudo sed -i '/ swap / s/^\(.*\)$/#\1/g' /etc/fstab

# Disable SELinux (or set to permissive)
sudo setenforce 0
sudo sed -i 's/^SELINUX=enforcing$/SELINUX=permissive/' /etc/selinux/config

# Configure kernel modules
sudo modprobe overlay
sudo modprobe br_netfilter

cat << EOF | sudo tee /etc/modules-load.d/k8s.conf
overlay
br_netfilter
EOF

# Configure sysctl parameters
cat << EOF | sudo tee /etc/sysctl.d/k8s.conf
net.bridge.bridge-nf-call-iptables  = 1
net.bridge.bridge-nf-call-ip6tables = 1
net.ipv4.ip_forward                 = 1
EOF

sudo sysctl --system

# Configure firewall (Master node)
sudo firewall-cmd --permanent --add-port=6443/tcp
sudo firewall-cmd --permanent --add-port=2379-2380/tcp
sudo firewall-cmd --permanent --add-port=10250/tcp
sudo firewall-cmd --permanent --add-port=10251/tcp
sudo firewall-cmd --permanent --add-port=10252/tcp
sudo firewall-cmd --permanent --add-port=10255/tcp
sudo firewall-cmd --permanent --add-masquerade
sudo firewall-cmd --reload

# Configure firewall (Worker nodes)
sudo firewall-cmd --permanent --add-port=10250/tcp
sudo firewall-cmd --permanent --add-port=30000-32767/tcp
sudo firewall-cmd --permanent --add-masquerade
sudo firewall-cmd --reload

Installing Container Runtime (containerd)

# Install containerd
sudo dnf config-manager --add-repo https://download.docker.com/linux/centos/docker-ce.repo
sudo dnf install -y containerd.io

# Configure containerd
sudo containerd config default | sudo tee /etc/containerd/config.toml

# Enable SystemdCgroup
sudo sed -i 's/SystemdCgroup = false/SystemdCgroup = true/g' /etc/containerd/config.toml

# Start containerd
sudo systemctl enable --now containerd

# Verify containerd
sudo systemctl status containerd

🔧 Installing Kubernetes Components

Time to install Kubernetes on all nodes! 🌟

Installing kubeadm, kubelet, and kubectl

# Add Kubernetes repository
cat << EOF | sudo tee /etc/yum.repos.d/kubernetes.repo
[kubernetes]
name=Kubernetes
baseurl=https://packages.cloud.google.com/yum/repos/kubernetes-el7-x86_64
enabled=1
gpgcheck=1
repo_gpgcheck=1
gpgkey=https://packages.cloud.google.com/yum/doc/yum-key.gpg https://packages.cloud.google.com/yum/doc/rpm-package-key.gpg
exclude=kubelet kubeadm kubectl
EOF

# Install Kubernetes components
sudo dnf install -y kubelet kubeadm kubectl --disableexcludes=kubernetes

# Enable kubelet
sudo systemctl enable --now kubelet

# Check versions
kubeadm version
kubectl version --client
kubelet --version

Initializing the Master Node

# On Master node only
# Initialize cluster with pod network CIDR
sudo kubeadm init --pod-network-cidr=10.244.0.0/16 --apiserver-advertise-address=192.168.1.10

# Save the join command output! You'll need it for workers

# Configure kubectl for regular user
mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config

# Verify cluster status
kubectl get nodes
kubectl get pods --all-namespaces

# Install Calico network plugin
kubectl create -f https://raw.githubusercontent.com/projectcalico/calico/v3.26.0/manifests/tigera-operator.yaml
kubectl create -f https://raw.githubusercontent.com/projectcalico/calico/v3.26.0/manifests/custom-resources.yaml

# Wait for all pods to be running
watch kubectl get pods -n calico-system

# Verify node is Ready
kubectl get nodes

🌟 Joining Worker Nodes

Let’s add worker nodes to the cluster! 🔗

Joining Workers to Cluster

# On each worker node, run the join command from master init output
# Example (use your actual command):
sudo kubeadm join 192.168.1.10:6443 --token abcdef.0123456789abcdef \
    --discovery-token-ca-cert-hash sha256:1234567890abcdef1234567890abcdef1234567890abcdef1234567890abcdef

# If you lost the join command, generate a new one on master:
kubeadm token create --print-join-command

# On master, verify all nodes joined
kubectl get nodes

# Label worker nodes
kubectl label node worker1.k8s.local node-role.kubernetes.io/worker=worker
kubectl label node worker2.k8s.local node-role.kubernetes.io/worker=worker

Installing Kubernetes Dashboard

# Deploy dashboard
kubectl apply -f https://raw.githubusercontent.com/kubernetes/dashboard/v2.7.0/aio/deploy/recommended.yaml

# Create admin user for dashboard
cat << EOF | kubectl apply -f -
apiVersion: v1
kind: ServiceAccount
metadata:
  name: admin-user
  namespace: kubernetes-dashboard
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: admin-user
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: cluster-admin
subjects:
- kind: ServiceAccount
  name: admin-user
  namespace: kubernetes-dashboard
EOF

# Get login token
kubectl -n kubernetes-dashboard create token admin-user

# Access dashboard (create SSH tunnel first)
kubectl proxy

# Browse to: http://localhost:8001/api/v1/namespaces/kubernetes-dashboard/services/https:kubernetes-dashboard:/proxy/

✅ Deploying Applications

Let’s deploy your first applications on Kubernetes! 🚀

Deploying a Sample Application

# Create nginx deployment
cat << EOF | kubectl apply -f -
apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx-deployment
  labels:
    app: nginx
spec:
  replicas: 3
  selector:
    matchLabels:
      app: nginx
  template:
    metadata:
      labels:
        app: nginx
    spec:
      containers:
      - name: nginx
        image: nginx:latest
        ports:
        - containerPort: 80
---
apiVersion: v1
kind: Service
metadata:
  name: nginx-service
spec:
  selector:
    app: nginx
  type: LoadBalancer
  ports:
    - protocol: TCP
      port: 80
      targetPort: 80
EOF

# Check deployment status
kubectl get deployments
kubectl get pods
kubectl get services

# Scale deployment
kubectl scale deployment nginx-deployment --replicas=5

# Check pod distribution across nodes
kubectl get pods -o wide

Setting Up Persistent Storage

# Create StorageClass for dynamic provisioning
cat << EOF | kubectl apply -f -
apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: local-storage
provisioner: kubernetes.io/no-provisioner
volumeBindingMode: WaitForFirstConsumer
EOF

# Create PersistentVolume
cat << EOF | kubectl apply -f -
apiVersion: v1
kind: PersistentVolume
metadata:
  name: pv-volume
  labels:
    type: local
spec:
  storageClassName: local-storage
  capacity:
    storage: 10Gi
  accessModes:
    - ReadWriteOnce
  hostPath:
    path: "/mnt/data"
EOF

# Create PersistentVolumeClaim
cat << EOF | kubectl apply -f -
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: pv-claim
spec:
  storageClassName: local-storage
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 3Gi
EOF

# Deploy MySQL with persistent storage
cat << EOF | kubectl apply -f -
apiVersion: apps/v1
kind: Deployment
metadata:
  name: mysql
spec:
  selector:
    matchLabels:
      app: mysql
  strategy:
    type: Recreate
  template:
    metadata:
      labels:
        app: mysql
    spec:
      containers:
      - image: mysql:5.7
        name: mysql
        env:
        - name: MYSQL_ROOT_PASSWORD
          value: password123
        ports:
        - containerPort: 3306
          name: mysql
        volumeMounts:
        - name: mysql-storage
          mountPath: /var/lib/mysql
      volumes:
      - name: mysql-storage
        persistentVolumeClaim:
          claimName: pv-claim
EOF

🎮 Quick Examples

Example 1: Deploying Microservices Application

# Deploy a complete microservices stack
cat << 'EOF' | kubectl apply -f -
# Frontend Service
apiVersion: apps/v1
kind: Deployment
metadata:
  name: frontend
spec:
  replicas: 3
  selector:
    matchLabels:
      app: frontend
  template:
    metadata:
      labels:
        app: frontend
    spec:
      containers:
      - name: frontend
        image: nginx:alpine
        ports:
        - containerPort: 80
        env:
        - name: BACKEND_URL
          value: "http://backend-service:8080"
---
apiVersion: v1
kind: Service
metadata:
  name: frontend-service
spec:
  selector:
    app: frontend
  ports:
  - port: 80
    targetPort: 80
  type: LoadBalancer
---
# Backend Service
apiVersion: apps/v1
kind: Deployment
metadata:
  name: backend
spec:
  replicas: 2
  selector:
    matchLabels:
      app: backend
  template:
    metadata:
      labels:
        app: backend
    spec:
      containers:
      - name: backend
        image: httpd:alpine
        ports:
        - containerPort: 8080
---
apiVersion: v1
kind: Service
metadata:
  name: backend-service
spec:
  selector:
    app: backend
  ports:
  - port: 8080
    targetPort: 80
EOF

# Check services
kubectl get all
kubectl get endpoints

Example 2: Setting Up Ingress Controller

# Install NGINX Ingress Controller
kubectl apply -f https://raw.githubusercontent.com/kubernetes/ingress-nginx/controller-v1.8.1/deploy/static/provider/baremetal/deploy.yaml

# Create Ingress rules
cat << EOF | kubectl apply -f -
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: app-ingress
  annotations:
    nginx.ingress.kubernetes.io/rewrite-target: /
spec:
  ingressClassName: nginx
  rules:
  - host: app.example.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: frontend-service
            port:
              number: 80
      - path: /api
        pathType: Prefix
        backend:
          service:
            name: backend-service
            port:
              number: 8080
EOF

# Get Ingress status
kubectl get ingress
kubectl describe ingress app-ingress

Example 3: Monitoring with Prometheus and Grafana

# Add Prometheus Helm repository
helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
helm repo update

# Install Prometheus stack
helm install prometheus prometheus-community/kube-prometheus-stack \
  --namespace monitoring --create-namespace

# Port-forward to access Grafana
kubectl port-forward -n monitoring svc/prometheus-grafana 3000:80

# Default credentials: admin/prom-operator

# Deploy application with metrics
cat << EOF | kubectl apply -f -
apiVersion: apps/v1
kind: Deployment
metadata:
  name: metrics-app
spec:
  replicas: 3
  selector:
    matchLabels:
      app: metrics-app
  template:
    metadata:
      labels:
        app: metrics-app
      annotations:
        prometheus.io/scrape: "true"
        prometheus.io/port: "8080"
        prometheus.io/path: "/metrics"
    spec:
      containers:
      - name: app
        image: prom/node-exporter
        ports:
        - containerPort: 9100
EOF

🚨 Fix Common Kubernetes Problems

Let’s solve the most frequent K8s issues! 🛠️

Problem 1: Pods Stuck in Pending State

Symptoms: Pods won’t start, stuck in Pending Solution:

# Check pod events
kubectl describe pod pod-name

# Common causes and fixes:
# 1. No nodes available
kubectl get nodes
kubectl taint nodes --all node-role.kubernetes.io/master-

# 2. Insufficient resources
kubectl describe nodes | grep -A 5 "Allocated resources"

# 3. PVC not bound
kubectl get pvc
kubectl describe pvc pvc-name

Problem 2: Node Not Ready

Symptoms: Node shows NotReady status Solution:

# Check node status
kubectl describe node node-name

# Check kubelet logs
sudo journalctl -u kubelet -f

# Common fixes:
# Restart kubelet
sudo systemctl restart kubelet

# Check container runtime
sudo systemctl status containerd
sudo systemctl restart containerd

# Check network plugin
kubectl get pods -n kube-system | grep calico

Problem 3: Service Not Accessible

Symptoms: Can’t reach service from outside cluster Solution:

# Check service and endpoints
kubectl get svc
kubectl get endpoints

# Test service internally
kubectl run test --image=busybox -it --rm -- sh
# Inside pod:
wget -O- service-name:port

# Check iptables rules
sudo iptables -t nat -L -n | grep service-port

# Use NodePort for external access
kubectl patch svc service-name -p '{"spec":{"type":"NodePort"}}'

Problem 4: Image Pull Errors

Symptoms: ImagePullBackOff errors Solution:

# Check pod events
kubectl describe pod pod-name

# Create image pull secret
kubectl create secret docker-registry regcred \
  --docker-server=docker.io \
  --docker-username=username \
  --docker-password=password \
  [email protected]

# Use secret in deployment
kubectl patch deployment deployment-name -p '{"spec":{"template":{"spec":{"imagePullSecrets":[{"name":"regcred"}]}}}}'

📋 Essential Kubernetes Commands

Master these K8s commands for daily operations! ⚡

💡 Kubernetes Best Practices

Become a K8s expert with these pro tips! 🎯

• 📝 Use Namespaces - Organize resources logically
• 🏷️ Label Everything - Use labels for organization and selection
• 📊 Set Resource Limits - Prevent resource exhaustion
• 🔐 RBAC Security - Implement role-based access control
• 💾 Persistent Storage - Use PVCs for stateful apps
• 🔄 Health Checks - Configure liveness and readiness probes
• 📈 Monitor Everything - Deploy metrics and logging
• 🔧 GitOps Workflow - Store configs in version control
• 🚀 Rolling Updates - Use deployment strategies
• 💡 Documentation - Document your cluster architecture

🏆 What You’ve Accomplished

Congratulations on mastering Kubernetes on AlmaLinux! 🎉 You’ve achieved:

• ✅ Complete K8s cluster deployed from scratch
• ✅ Master and worker nodes configured properly
• ✅ Container networking with Calico installed
• ✅ Application deployments successfully running
• ✅ Persistent storage configured for stateful apps
• ✅ Ingress controller for external access
• ✅ Dashboard access for GUI management
• ✅ Monitoring stack with Prometheus/Grafana
• ✅ Troubleshooting skills for common issues
• ✅ Best practices implemented throughout

🎯 Why These Skills Matter

Your Kubernetes expertise enables cloud-native transformation! 🌟 With these skills, you can:

Immediate Benefits:

• 🚀 Deploy applications in seconds, not hours
• 🔄 Achieve zero-downtime deployments
• 📈 Scale from 1 to 1000s of containers instantly
• 💰 Optimize resource utilization by 50% or more

Long-term Value:

• ☁️ Build cloud-native architectures
• 🌍 Deploy globally distributed applications
• 💼 Become a sought-after DevOps engineer
• 🏆 Lead digital transformation initiatives

You’re now equipped to orchestrate containerized applications at any scale, from startup MVPs to enterprise platforms serving millions! Kubernetes is your superpower! 🌟

Keep orchestrating, keep scaling! 🙌
